NI SCXI-1325 Terminal Block

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

NI SCXI-1325Functional Features

Connection Mode
Equipped with 26 screw terminals, including 2 connected to the chassis ground of SCXI-1124 and 24 for signal connection with the 6 output channels of the SCXI-1124 module. It enables direct connection to sensors via front-panel-mounted BNC connectors or screw terminals.
Electrical Isolation
Provides 250V rms isolation between channels and to ground, ensuring signal accuracy and safety in high common-mode voltage environments while reducing cross-channel interference.
High-Precision Design
Adopts an isothermal structure to ensure high measurement accuracy and minimize measurement errors caused by temperature fluctuations.

Technical Specifications

Typical Application Scenarios

Industrial Automation Control
Used in automated production lines to connect and control analog output devices (e.g., frequency converters, servo drives), enabling precise control of motor speed, position, and other parameters to ensure stable and consistent production processes.
Process Control Systems
Collaborates with various sensors and actuators in process control systems of chemical, petroleum, power, and other industries to monitor and control process variables (e.g., temperature, pressure, flow), ensuring safe and efficient production operations.
Laboratory Testing and Research
Applied in scientific laboratories and testing environments to build analog signal testing systems, facilitating connection and switching of different testing equipment and sensors for signal acquisition, analysis, and experimental research.

Working Principle

Signal Connection and Transmission
Connects external devices (e.g., sensors, actuators) to the SCXI-1124 analog output module via screw terminals. When the SCXI-1124 module outputs analog signals, they are transmitted to external devices through the SCXI-1325's screw terminals for signal transmission and control. Meanwhile, SCXI-1325 can also transmit feedback signals from external devices back to the SCXI-1124 module or other related modules for processing and analysis.
Electrical Isolation and Protection
Achieves 250V rms electrical isolation between channels and to ground through internal isolation circuits and structures. This isolation prevents external electrical interference from entering the system, avoids cross-channel signal interference within the system, and improves signal stability and accuracy. Additionally, it protects equipment and personnel by preventing electric shock or equipment damage caused by electrical faults.
Isothermal Structure for Accuracy
The isothermal structure design ensures uniform temperature across the terminal block. Since analog signal transmission and processing are sensitive to temperature, uneven temperatures may cause signal drift and errors. The isothermal structure reduces the impact of temperature changes on signals, ensuring high-precision signal measurement and transmission.
