NI SCXI-1326I. Functional Features
  • High-Density Terminal Connection
    Equipped with 48 screw terminals, it collaborates with relay modules like SCXI-1161 to enable switching and routing of multi-channel signals, suitable for complex signal switching scenarios.
  • Shielded and Anti-Interference Design
    As a shielded terminal block, it reduces electromagnetic interference (EMI) and radio-frequency interference (RFI) through grounding design and shielding layers, ensuring stable signal transmission.
  • High-Voltage Compatibility
    Supports high-voltage signal processing. Combined with relay modules, it enables switching control of high-voltage circuits, meeting the signal conditioning requirements of high-voltage equipment in industrial environments.
  • Flexible Channel Configuration
    The terminal layout supports parallel connection of multiple channels, corresponding to internal contacts of relay modules to achieve flexible signal routing and switching.
II. Technical Specifications
  • Electrical Isolation
    Common-mode isolation between channels and to ground is 250V rms, ensuring signal safety and anti-interference capability in high-voltage environments.
  • Current Load Capacity
    Maximum load current per channel is 2A, adapting to current requirements of various industrial sensors and actuators.
  • Wiring Specifications
    Supports cable access of 26-16AWG, compatible with common industrial cable specifications for convenient on-site wiring.
  • Operating Environment

    • Operating temperature: 0°C to 50°C

    • Storage temperature: -20°C to 70°C

    • Relative humidity: 5% to 90% (non-condensing), adapting to temperature and humidity changes in industrial fields.

SCXI-1326 (6)

SCXI-1326 (9)

III. Typical Application Scenarios
  • Industrial Automation Signal Switching
    Used in production lines for switching and acquisition of multi-channel sensor signals (e.g., temperature, pressure) or control of on/off states of multi-channel actuators (e.g., solenoid valves, contactors) to achieve efficient control of automated processes.
  • Power System Testing and Monitoring
    In substation or power equipment testing, collaborates with relay modules to monitor and control the switching status of high-voltage circuits, ensuring safe operation of the power system.
  • Laboratory Multi-Channel Signal Routing
    Used in scientific research testing to build multi-channel signal switching platforms, facilitating quick access and switching of different testing equipment or sensors to improve experimental efficiency.
  • Process Control and Data Acquisition
    In chemical, petroleum, and other industries, collaborates with data acquisition modules to condition and acquire multi-channel process signals (e.g., flow, liquid level), providing accurate data support for system control.
IV. Working Principle
  1. Signal Routing and Relay Collaboration Mechanism

  • Hardware Connection with Relay Modules
    The 48 screw terminals of SCXI-1326 correspond to the 16 relay contacts of relay modules like SCXI-1161, achieving signal channel switching through the open/close state of relays. For example:

    • When the relay coil is powered, the contact closes, and the terminals of SCXI-1326 connect to the target circuit (e.g., sensor or acquisition module).

    • When the relay is powered off, the contact opens, cutting off the signal path to achieve safe isolation.

  • Signal Flow
    External signals (e.g., sensor outputs) are connected to SCXI-1326 via screw terminals, switched by relay contacts, and transmitted to subsequent data acquisition modules (e.g., SCXI-1125) or execution devices, forming a complete chain of "signal input-switching-processing".

  • Electrical Isolation and Anti-Interference Design

    • Isolation Mechanism
      Achieves 250V rms electrical isolation between channels and to ground through transformer isolation or optocoupler isolation, preventing common-mode voltage interference (e.g., ground loop noise) from affecting signal quality and avoiding system damage in high-voltage environments.

    • Shielding and Grounding
      The shielding layer of the terminal block can be connected to the chassis ground to form a Faraday cage effect, suppressing external electromagnetic interference; the cable shielding layer is grounded via grounding terminals to further reduce noise coupling.

  • Isothermal Structure and Accuracy Assurance
    Adopts the isothermal copper plane design consistent with the SCXI series, integrating all terminals on the same heat-conducting plane to reduce temperature gradients between terminals, avoid signal drift caused by temperature differences (e.g., cold junction temperature fluctuations in thermocouple measurements), and ensure high-precision measurement.
  • Open Circuit Detection and Fault Diagnosis
    Each channel is equipped with a pull-up resistor (e.g., CH+ to +5V) and a bias resistor (CH- to ground). When external cables or sensors are open-circuited, the differential input signal exceeds the normal range, and the SCXI module can detect this anomaly through software to achieve fault early warning and ensure system reliability.
  • Collaborative Workflow with SCXI System

    • Hardware Connection
      SCXI-1326 connects to the chassis via the SCXI bus to obtain power and transmit control signals (e.g., relay drive commands).

    • Signal Processing
      The relay module controls the contact state according to instructions from the host computer (e.g., LabVIEW), and SCXI-1326 completes signal routing; the signal is conditioned, transmitted to the acquisition module, and converted to digital quantity via ADC.

    • Software Integration
      Utilizes NI drivers and software tools to configure relay logic, read signal status, and integrate algorithms such as cold junction compensation (if temperature measurement is involved) to achieve real-time data processing and display.

    SCXI-1326 (8)

    SCXI-1326 (5)

    V. Core Technology Comparison (with SCXI-1324/1325)
    Module Model SCXI-1324 SCXI-1325 SCXI-1326
    Core Function High-voltage switching signal conditioning Analog signal connection and isolation Multi-channel signal routing and switching
    Number of Terminals 48 (connecting 16 relays) 26 (connecting 6 output channels) 48 (connecting 16 relays)
    Typical Matching Modules SCXI-1160 (relay) SCXI-1124 (analog output) SCXI-1161 (relay)
    Application Scenarios High-voltage equipment control Analog output control Multi-channel signal switching and testing
