Triconex 3626X Digital output module

Functional characteristics:

Signal output: The main function is to output the digital signals of the control system to external devices, which can drive relays, solenoid valves and other actuating elements to achieve on-off control of various equipment in industrial processes, such as controlling the opening and closing of valves, the start and stop of motors, etc.

Electrical isolation: It is equipped with electrical isolation function, which can effectively isolate the internal circuit of the module from the external circuit, preventing external electrical interference from affecting the normal operation of the module and the entire control system. At the same time, it can also avoid damage to external equipment caused by module failure, improving the stability and reliability of the system.

Diagnostic function: It usually has a self-diagnostic function, which can monitor the working status of the module in real time, such as detecting whether the output channel is normal, and whether there are short circuits or open circuits and other faults. When a fault is detected, the module will send a fault signal to the control system, facilitating the operator to discover and handle the problem in a timely manner.

Redundant design: To meet the high reliability requirements of industrial sites, redundant configuration may be supported. Through redundant connections, when one module fails, the other module can continue to work, ensuring that the control function of the system is not interrupted.

Technical parameters:

Working voltage: Generally 24VDC, but the specific voltage range may vary depending on the product model and configuration. Please refer to the product manual.

Number of output channels: It usually has multiple output channels, with 16 channels being common, allowing for simultaneous control of multiple external devices.

Load capacity per channel: Each output channel can provide a certain load current, such as 0.5A, which can meet the driving requirements of most conventional industrial field actuators.

Communication interface: An interface that supports communication with the control system, which may be a bus interface such as Profibus, Modbus, etc., in order to upload the module status information to the control system and receive control instructions.

Application scenarios:

Petrochemical industry: It is used for the control of various valves and pumps in chemical production facilities, as well as emergency shutdown systems, etc., to ensure the safety and stable operation of the production process.

Power industry: It can control circuit breakers, contactors and other equipment in the power system, achieve control over power distribution and transmission, and participate in the automation control and protection system of substations.

Metallurgical industry: On metallurgical production lines, it is used to control the start, stop and speed switching of blast furnace material distribution equipment and steel rolling mills, ensuring the smooth operation of the production process.

Other industrial fields: In the pharmaceutical, food and beverage, papermaking and other industrial fields, it can also be used to control the operating status of production equipment and achieve the automatic control of the production process.
