Triconex 2301 Isolates the Analog Input Module

Triconex 2301 isolates the analog input module

Number of channels: It features 8 analog input channels, capable of simultaneously collecting multiple analog signals to meet various application requirements.

Input types: Supports multiple input types such as voltage, current, thermocouple and RTD, which can be adapted to different sensors and measurement scenarios.

Resolution: 12 bits, which can ensure the accuracy of the measurement data.

Conversion time: Only 5 milliseconds, capable of quickly converting analog signals into digital signals to achieve real-time data acquisition.

Common-mode suppression: Reaching 60dB, it has a strong common-mode interference suppression capability, which can ensure the stability of measurement data.

Anti-noise capability: It can withstand 5V peak-to-peak noise and operate stably in complex industrial electromagnetic environments.

Operating temperature: Range from -40 °C to 75°C, suitable for harsh industrial environments.

Storage temperature: -40 °C to 85°C.

Relative humidity: 5% to 95% (non-coated), and it can operate normally in a certain humidity environment.

Vibration resistance: Can withstand vibrations ranging from 5g to 2,000Hz, with inter-peak values.

Impact resistance: Can withstand a 5g impact lasting 22 milliseconds.

Dimensions: 114mm x 89mm x 25mm. Compact in size, it saves installation space.

Weight: Approximately 0.3 kilograms.

Installation method: DIN rail installation is adopted, which is convenient for installation.

Application case:

Petrochemical industry: In oil refineries, it can be used in compressor control systems (CCS). By connecting pressure sensors, temperature sensors, etc., the 2301 module collects analog signals such as pressure and temperature during the operation of the compressor, converts them into digital signals and transmits them to the control system, enabling operators to monitor the status of the compressor in real time and adjust the operating parameters of the compressor based on the signal feedback to ensure it operates within a safe range.

In the power industry, it can be applied to the boiler combustion control system in thermal power plants. This module can collect temperature signals from thermocouples and steam pressure signals from pressure sensors, etc., providing accurate analog data for the control system to achieve precise control of parameters such as boiler combustion temperature and steam pressure, ensuring the safe and stable operation of the boiler and improving power generation efficiency.

Water treatment industry: In sewage treatment plants, it can be used to monitor the flow and liquid level of sewage. The 2301 module connects the flow sensor and the liquid level sensor to collect the flow data of the sewage entering the treatment equipment and the liquid level data in the water tank, providing a basis for the automatic control of the sewage treatment process, helping the staff to reasonably arrange the treatment process, and ensuring the sewage treatment effect and the normal operation of the equipment.

In the metallurgical industry, during the blast furnace ironmaking process in steel mills, it can be used to collect analog signals of temperature and pressure inside the blast furnace. By monitoring these signals in real time, the control system can promptly understand the internal working conditions of the blast furnace, adjust operations such as material distribution and air blowing, ensure the stable operation of the blast furnace, and improve the quality and output of molten iron.

In the automotive manufacturing industry, it can be used to control the paint conveying system in the automotive painting production line. This module collects analog signals such as paint pressure and flow rate, and precisely adjusts the paint delivery volume and pressure according to the production process requirements to ensure uniform and consistent vehicle body coating quality, while avoiding problems such as paint waste and dripping.
