US-3D710 3D Wire Bending Machine

Guangdong Yonghou Technology Holding Co., Ltd. Verified Business License
US-3D710 3D Wire Bending Machine thumbnail-1
US-3D710 3D Wire Bending Machine thumbnail-2
US-3D710 3D Wire Bending Machine thumbnail-3
US-3D710 3D Wire Bending Machine photo-1
US-3D710 3D Wire Bending Machine photo-2
US-3D710 3D Wire Bending Machine photo-3
US$ 50000 ≥1 Piece
Key Specifications
Get Latest Price
Brand Name:
unionspring
Place of Origin:
China
Model Number:
US-3D710
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name unionspring
Place of Origin China
Model Number US-3D710
After-sales Service Provided Engineers available to service machinery overseas
Condition New

3D Wire Bending Machine

Model

US-3D706

US-3D710

Wire Diameter

Ø2.5～Ø6.0MM

Ø5.0～Ø10.0MM

Axis

7

7

Wire Feed Wheel Sets

2Sets

3Sets

Wire Feeding Axis

2.7KW

4.5KW

Wire Rotary Axis

2.0KW

2.7KW

External Torsion Axis

2.0KW

4.5KW

Internal Torsion Axis

2.0KW

5.5KW

Torsion Head Lift Axis

1.0KW

2.0KW

Platform Lifting Axis

0.75KW

1.0KW

Cutter Axis

2.0KW

5.5KW

Dimension (LxWxH)

2800*1200*1700(mm)

3400*1300*1750(mm)

Weight (kg)

2200kg

3800kg





Machine features:


1. The machine adopts computer control system and imported servo motor to ensure the stability of processed products.


2. Based on the working conditions on the computer display of the equipment, the angle, length, parameters, etc. of the product can be corrected.


3. The computer has Chinese and English (optional) interfaces, which are simple to operate and accurate in positioning. All motors can run synchronously or single-step.


4. It has an automatic shutdown alarm function when wireless, disconnected or wound, which increases the safety performance of the equipment.


5. The machine can be freely equipped with functions such as automatic welding machine, chamfering, grooving, flattening, punching, threading, flat steel strip punching and bending.


3d_202503261706373d 202503261707013d _20250326170713




Product Tags: 3D Wire , Bending Machine , CNC Coiler
