Home > Products > bending machine > US-TP35-7 Copper Busbar Punching, Bending, and Forming Integrated Machine
US-TP35-7 Copper Busbar Punching, Bending, and Forming Integrated Machine
≥1 Piece
- 500 Piece / Pieces per Month
- T/T L/C PayPal D/P Western Union Other
You May Like
Product Details
Brand Name | unionspring | Place of Origin | China | |
Model Number | US-TP35-7 | After-sales Service Provided | Engineers available to service machinery overseas | |
Condition | New | Machine Type | Beading Machine | |
Automation | Automatic | Power | Cnc |
Product Description
Model | UN-TP35-7 | |
Maximum Processing Range | 35mm*7mm | |
Punching Power | 7.5KW | |
Wire Feeding Shaft Power | 2.7KW | |
Coiling Shaft Power | 2KW*2 | |
Arm Shaft Power | 2KW*3 | |
Servo Shearing Power | 2KW | |
Machine Dimensions (LWH mm) | 2600*2000*2100 | |
Machine Weight | 2500KG |
1.The machine adopts a unique camless and rocker-arm-free design, significantly reducing the technical requirements for setup and shortening setup time. The setup speed is over 50% faster than traditional cam-based machines, ensuring high production speed, precise positioning, stable operation, and strong expandability.
2.Equipped with imported motors, precision bearings, and imported guide rails, it enhances motion accuracy, ensures stable and durable operation, and effectively extends the machine's lifespan.
3.The intelligent professional-grade industrial computer operating system supports multiple languages, features an easy-to-understand and user-friendly interface, and offers powerful functionality to meet complex multi-task requirements.
4.The system includes protective mechanisms such as operating system safeguards, wire feeding frame breakage alarms, and safety door protection, providing comprehensive protection for both operators and the machine.
00001. 1.Closed-loop control system: Maximum response speed of 4000 kpps, achieving a speed of 240 meters per minute at a resolution of 1 µm.
00002. 2.Highly integrated system hardware: Minimizes failure rates and significantly enhances stability.
00003. 3.Software upgradability: Customers can upgrade the system software via the computer at any time. The user-friendly operation is complemented by a standard keyboard, making it easy to learn and use.
00004. 4.On-the-fly adjustments: Modify processing programs and adjust machine speed using the handwheel without stopping the machine.
00005. 5.Efficient repetitive programming: Combined with adjustable probe speed, it greatly improves production efficiency for applications like flat springs that require multiple probe cycles.
00006. 6.Comprehensive safety design:
· Emergency stop cuts off the Servo On signal.
· Motor overspeed system provides early warning.
· Safety door protection mechanism.
· Automatic shutdown for material breakage or wire frame abnormalities.
· Fault alarm with automatic shutdown.
· Wire frame follow-up function.
00007. 7.Superior noise immunity: Compared to general PC-based controllers, it offers stronger resistance to signal interference during operation, with a maximum voltage pulse of 3000 volts per microsecond within every 0.01-second interval.
00008. 8.Enhanced vibration resistance and temperature adaptability:
· Better vibration resistance (maximum 0.075 mm at 5 Hz).
· Wider temperature range for operation (0°C to 45°C) and storage/transportation (-20°C to 45°C).
