ZJ40T/2250 Trailer-Mounted Drilling Rig-supply of China

ZJ40T/2250 Trailer-Mounted Drilling Rig-supply of China thumbnail-1
ZJ40T/2250 Trailer-Mounted Drilling Rig-supply of China photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Type:
Rotary Drilling Rig
Certification:
ISO9001,ISO14001,OHSAS18001,API Q1
Contact Supplier Request Quote Chat Now
Shanghai Banpin Intelligent Automation Equipment Co., LTD
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
pudong airport
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Type Rotary Drilling Rig
Certification ISO9001,ISO14001,OHSAS18001,API Q1
After-sales Service Provided Overseas service center available
Warranty 1
Dimension(L*W*H) 22.3 × 3.2 × 4.5M
Power Type Other, Hydraulic + Mechanical
Usage Ore
Condition New
Power(W) 2x470000

The ZJ40T/2250 Trailer-Mounted Drilling Rig is a specialized piece of equipment designed for oil and gas well drilling operations. Here are some key details about this drilling rig:

Description:

  • This drilling rig is suitable for drilling oil and gas wells with a drilling depth of up to 4000 meters.

  • It is mounted on a special four-axle semi-trailer chassis and features a double engine and compound gear power system.

  • The rig comes with a 38m or 39m hydraulic telescopic mast, which is essential for drilling operations.

Features:

  1. Hydraulic Transmission: Equipped with an Allison S series hydraulic transmission case, which offers low operation and maintenance costs.

  2. Semi-Trailer Chassis: The rig is placed on a special semi-trailer chassis, which allows for fast and cost-effective transportation.

  3. Braking System: The main brake of the draw-works can be either a disc brake or a belt brake, while the auxiliary brake is a pneumatic water-cooled disc brake.

  4. Layout and Maintenance: The rig is designed with a reasonable layout, providing reliable operational performance and low transportation costs. It is easy to install and maintain on-site.

  5. Caterpillar Diesel Engine: The drilling rig uses a Caterpillar diesel engine known for its reliable performance.

  6. Efficient Transportation: The rig's components, including the power system, draw-works, mast, traveling system, and transmission system, are placed on the semi-trailer chassis. The tractor can transport the rig to the oil field, improving transportation efficiency and resource savings.

Application:

  • This diesel-driven semi-trailer drilling rig is available in various configurations, with drilling depths ranging from 1500m to 4000m and maximum static loads from 1350KN to 2250KN.

  • It is suitable for use in open oil fields with good road conditions.

  • The rig is known for its heavy workload, reliable performance, strong cross-country capability, ease of transportation, low operational costs, and suitability for middle and shallow well drilling operations.

In summary, the ZJ40T/2250 Trailer-Mounted Drilling Rig is a versatile and mobile drilling equipment designed for a range of drilling depths and well types, offering efficiency and cost-effectiveness in oil and gas exploration and production.

Technical Parameter of Hydraulic Oil Well Drilling Rig

Item Name Parameter
1 Drilling depth(41/2″Drill Pipe) m 4000
2 Heavy repair depth(31/2 " Drill Pipe) m 7000
3 Max. hook load KN 2250
4 Hook speed (m/s) 0.2 to 1.4
5 Mast (m) 38/39
6 Mast type A-mast
7 Engine power (kW) 2 × 470
8 Hydraulic transmission case 2×M5620AR
9 Transmission type of trailer mounted drill equipment Hydraulic + mechanical
10 Traveling system 6 × 5
11 Main rope diameter (mm) φ32
12 Hook block model YG225
13 Swivel model SL225
14 Rotary table model ZP275
15 Chassis model XDP80/14×10
16 Approach / departure angle 26°/18°
17 Min. ground clearance (mm) 311
18 Overall dimension (m) 22.3 × 3.2 × 4.5

Product Tags: Drilling Rig , Truck-Mounted Drilling Rig , Well Drilling rig , Trailer Mounted Hydraulic Drilling Rig , Mechanical Trailer Mounted Drilling Machine , Truck Mounted Drill Equipment , Trailer Mounted Drilling Rig , Hydraulic Oil Well Drilling Rig , Hydraulic Drill
