Cummins KTA19 M/ KTA19 M500 Marine Engine

Name: Cummins KTA19 M/ KTA19 M500 Marine Engine
Brand: CUMMINS
Availability: InStock

FOB Price

US$ 5000 - 200000 / Piece

1 Piece(Min. Order)

Port shanghai
Payment TermsT/T
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	CUMMINS	Place of Origin	China
Model Number	Cummins KTA19 M/ KTA19 M500 Marine Engine	Type	Container Ship
Condition	New	Fuel Type	Diesel
Hull Material	IRON	DWT	10000 - 34999t
Length (m)	< 50m	Year Built	2022
TEU	10	Draft	10

Product Description

WE CAN SUPPLY CUMMINS KTA19 M/ KTA19 M500 marine engine
General Engine Data
Engine Model KTA19-M (cummins KTA19 M500 marine engine)
Displacement: 18.9 liter [1150 in³ ] Rated Power: 373 kw [500 bhp]
Bore: 159 mm [6.25 in] Rated Speed: 1800 rpm
Stroke: 159 mm [6.25 in] Rating Type: Continuous Duty
Fuel System: PT Aspiration: Turbocharged/aftercooled
Cylinders: 6
Rating Type Continuous Duty
Rated Engine Power kW [hp] 373 [500]
Rated Engine Speed rpm 1800
Rated Power Production Tolerance ± % 3
Rated Engine Torque N@m [lb@ft] 1978 [1459]
Peak Engine Torque @ 1400 rpm N@m [lb@ft] 2242 [1654]
Brake Mean Effective Pressure kPa [psi] 1318 [191]
Indicated Mean Effective Pressure kPa [psi] 1560 [226]
Maximum Allowable Engine Speed rpm N A
Maximum Torque Capacity from Front of Crank² N@m [lb@ft] 1978 [1459]
Compression Ratio 13 8: 1
Piston Speed m/sec [ft/min] 9 5 [1875]
Weight (Dry) - Engine Only - Average kg [lb] 2073 [4570]
Weight (Dry) - Engine With Heat Exchanger System - Average kg [lb] 2246 [4952]

NTA855-M SO13458 336KW/1800RPM IMO
NTA855-M SO13497 305KW/1744RPM
NTA855-M SO13510 271KW/1744RPM
NTA855-M SO13520 298KW/2100RPM IMO
NT855-M SO13638 110KW/1600RPM
NT855-M SO13639 140KW/1600RPM
NT855-M SO13640 160KW/1600RPM
NTA855-M SO13649 198KW/1600RPM
NTA855-M SO13650 220KW/1744RPM
NTA855-M SO13660 271KW/1744RPM
NTA855-M SO13662 336KW/2100RPM
NTA855-M SO13710 336KW/2100RPM
NTA855-M SO13711 298KW/1800RPM
N855-M SO13715 298KW/1800RPM IMO2
N855-M SO13716 261KW/1800RPM IMO2
N855-M SO13717 298KW/2100RPM IMO2
NT855-M SO13725 183KW/1744RPM
NTA855-M SO13732 110KW/1600RPM
KTA19-M SO40001 351KW/1800RPM IMO
KTA19-M SO40002 373KW/1800RPM IMO
KT19-M SO40021 317KW/1800RPM IMO
KTA19-M3 SO40028 447KW/1800RPM IMO
KTA19-M SO40036 410KW/2100RPM IMO
KTA19-M3 SO40044 477KW/1800RPM IMO
KTA19-M4 SO40077 522KW/2100RPM IMO
KTA19-M SO40197 351KW/1800RPM IMO
KTA19-M3 SO40200 434KW/1744RPM
KTA19-M3 SO40201 407KW/1744RPM
KTA19-M SO40203 339KW/1744RPM
KTA19-M SO40204 318KW/1744RPM
KT19-M SO40213 288KW/1744RPM
KT19-M SO40301 317KW/1800RPM IMO
KT19-M SO40302 288KW/1744RPM
KTA19-M SO40303 373KW/1800RPM IMO
KTA19-M SO40304 339KW/1744RPM
KTA19-M3 SO40305 407KW/1744RPM
KT19-M SO40336 373KW/1800RPM IMO
KTA19-M SO40366 339KW/1700RPM
KTA19-M3 SO40370 447KW/1800RPM IMO
KTA19-M3 SO40372 447KW/1800RPM BV
KTA19-M SO40373 258KW/1600RPM
KTA19-M SO40374 237KW/1600RPM
KTA19-M3 SO40379 373KW/1800RPM IMO
KT19-M SO40381 193KW/1600RPM
KTA19-M SO40382 373KW/1800RPM BV
KT19-M SO40397 220KW/1744RPM
KT19-M SO40398 203KW/1600RPM
KTA19-M SO40405 300KW/1744RPM
KTA19-M SO40406 288KW/1744RPM
KTA19-M SO40407 265KW/1744RPM
KTA19-M SO40413 373KW/1800RPM
K19-M SO40415 373KW/1800RPM IMO2
K19-M SO40416 410KW/2100RPM IMO2
K19-M SO40417 447KW/1800RPM IMO2
K19-M SO40418 477KW/1800RPM IMO2
KTA19-M SO40425 237KW/1600RPM
KTA19-M SO40426 258KW/1600RPM
K19-M SO40433 477KW/1800RPM IMO2
K19-M SO40436 373KW/1800RPM IMO2
K19-M SO40437 447KW/1800RPM IMO2
KT38-M SO60008 596KW/1800RPM IMO
KTA38-M0 SO60135 671KW/1800RPM IMO
KT38-M SO60137 543KW/1744RPM
KTA38-M1 SO60155 746KW/1800RPM IMO
KT38-M SO60170 582KW/1800RPM IMO
KTA38-M2 SO60180 895KW/1800RPM IMO
KT38-M SO60186 407KW/1744RPM
KTA38-M2 SO60240 895KW/1800RPM BV
KTA38-M1 SO60243 746KW/1800RPM
KT38-M SO60266 440KW/2100RPM
KTA38-M2 SO60270 895KW/1800RPM
KTA38-M2 SO60285 895KW/1800RPM BV
KTA38-M2 SO60287 407KW/1600RPM
KT38-M SO60288 350KW/1600RPM
K38-M SO60293 1007KW/1900RPM IMO2
K38-M SO60294 895KW/1800RPM IMO2
K38-M SO60298 671KW/1600RPM IMO2
K38-M SO60300 1007KW/1900RPM IMO2
K38-M SO60301 970KW/1800RPM IMO2
K38-M SO60302 560KW/1600RPM IMO2
K38-M SO60303 596KW/1800RPM IMO2
K38-M SO60304 634KW/1800RPM IMO2
K38-M SO60305 746KW/1800RPM IMO2
K38-M SO60306 821KW/1800RPM IMO2
K38-M SO60307 821KW/1800RPM IMO2
K38-M SO60308 969KW/1800RPM IMO2

KT19-M	KT19-M425	386/1744	425/1800
KT19-M	KT19-M425	386/1744	425/1800
KTA19-M	KTA19-M470	427/1744	470/1800
	KTA19-M500	455/1744	500/1800
	KTA19-M500	455/1744	500/1800
	KTA19-M550	500/2027	550/2100
	KTA19-M500	455/1744	500/1800
	KTA19-M500	455/1744	500/1800
	KTA19-M470	427/1744	470/1800
	KTA19-M550	500/2027	550/2100
	KTA19-M500	455/1744	500/1800
	KTA19-M470	427/1744	470/1800
	KTA19-M500	455/1744	500/1800
KTA19-M3	KTA19-M640	582/1744	640/1800
	KTA19-M600	545/1744	600/1800
	KTA19-M600	545/1744	600/1800
	KTA19-M600	545/1744	600/1800
KTA19-M4	KTA19-M700	636/1744	700/1800
KTA19-M4	KTA19-M700	636/2027	700/2100

MODEL	SO NO.	RATED POWER kw/RPM	MAX POWER kw/RPM	APPLICATION	CERTIFICATE
KTA19-M	SO40001	351/1800		marine propulsion	CCS/IMO
KTA19-M	SO40002	373/1800		marine propulsion	CCS/IMO
KTA19-D(M)	SO40008	336/1500		auxiliary power	CCS/IMO
KT19-M	SO40021	317/1800		marine propulsion	CCS/IMO
KTA19-M3	SO40028	447/1800		marine propulsion	CCS/IMO
KTA19-M	SO40036	410/2100		marine propulsion	CCS/IMO
KTA19-D(M)	SO40038	448/1500		auxiliary power	CCS/IMO
KTA19-M3	SO40044	477/1800		marine propulsion	CCS/IMO
KTA19-M4	SO40077	522/2100		marine propulsion	CCS/IMO
KTA19-D(M)	SO40163	448/1500		auxiliary power	CCS/IMO
KTA19-D(M)	SO40168	392/1800		auxiliary power	CCS/IMO
KTA19-D(M)	SO40185	336/1500		auxiliary power	CCS/IMO
KTA19-M	SO40197	351/1800		marine propulsion	CCS/IMO
KTA19-M3	SO40200	434/1744	477/1800	marine propulsion	CCS
KTA19-M3	SO40201	407/1744	447/1800	marine propulsion	CCS
KTA19-M	SO40203	339/1744	373/1800	marine propulsion	CCS
KTA19-M	SO40204	318/1744	351/1800	marine propulsion	CCS
KT19-M	SO40213	288/1744	317/1800	marine propulsion	CCS
KTA19-D(M)	SO40249	403/1500		auxiliary power	CCS/IMO
KTA19-D(M)	SO40257	463/1800		auxiliary power	CCS/IMO
KTA19-D(M)	SO40259	336/1500		auxiliary power	CCS/IMO
KTA19-D(M)	SO40260	403/1500		auxiliary power	CCS/IMO
KTA19-D(M)	SO40261	448/1500		auxiliary power	CCS/IMO
KTA19-D(M)	SO40274	507/1800		auxiliary power	CCS/IMO
KT19-M	SO40301	317/1800		marine propulsion	CCS/IMO
KT19-M	SO40302	288/1744	317/1800	marine propulsion	CCS
KTA19-M	SO40303	373/1800		marine propulsion	CCS/IMO
KTA19-M	SO40304	339/1744	373/1800	marine propulsion	CCS
KTA19-M3	SO40305	407/1744	447/1800	marine propulsion	CCS
KT19-M	SO40336	373/1800		marine propulsion	CCS/IMO
KTA19-D(M)	SO40350	392/1800		auxiliary power	BV Class
KTA19-D(M)	SO40351	336/1500		auxiliary power	BV Class
KTA19-D(M)	SO40353	463/1800		auxiliary power	NK
KTA19-D(M)	SO40354	448/1500		auxiliary power	BV Class
KTA19-D(M)	SO40356	463/1800		auxiliary power	BV Class
KTA19-D(M)	SO40364	448/1500		auxiliary power	BV Class
KTA19-D(M)	SO40365	507/1800		auxiliary power	BV Class
KTA19-M	SO40366	339/1700	373/1755	marine propulsion	CCS
KTA19-M3	SO40370	447/1800		marine propulsion	CCS/IMO
KTA19-M3	SO40372	447/1800		marine propulsion	BV Class
KTA19-M	SO40373	258/1600	284/1652	marine propulsion	CCS
KTA19-M	SO40374	237/1600	261/1652	marine propulsion	CCS
KTA19-M3	SO40379	373/1800		marine propulsion	CCS/IMO
KT19-M	SO40381	193/1600	212/1652	marine propulsion	CCS
KTA19-M	SO40382	373/1800		marine propulsion	BV Class
KT19-M	SO40397	220/1744	242/1800	marine propulsion	CCS
KT19-M	SO40398	203/1600	223/1652	marine propulsion	CCS
KTA19-M	SO40405	300/1744	330/1800	marine propulsion	CCS
KTA19-M	SO40406	288/1744	317/1800	marine propulsion	CCS
KTA19-M	SO40407	265/1744	292/1800	marine propulsion	CCS
KTA19-D(M)	SO40412	463/1800		auxiliary power	CCS/IMO
KTA19-M	SO40413	373/1800		marine propulsion	CCS
K19-M	SO40415	373/1800		marine propulsion	CCS/IMO TIRE2
K19-M	SO40416	410/2100		marine propulsion	CCS/IMO TIRE2
K19-M3	SO40417	447/1800		marine propulsion	CCS/IMO TIRE2
K19-M3	SO40418	477/1800		marine propulsion	CCS/IMO TIRE2
K19-DM	SO40419	448/1500	503/1500	auxiliary power	CCS/IMO TIRE2
K19-DM	SO40420	507/1800	563/1800	auxiliary power	CCS/IMO TIRE2
K19-DM	SO40421	358/1500	395/1500	auxiliary power	CCS/IMO TIRE2
K19-DM	SO40422	410/1500	451/1500	auxiliary power	CCS/IMO TIRE2
K19-DM	SO40423	425/1800	470/1800	auxiliary power	CCS/IMO TIRE2
K19-DM	SO40424	485/1800	533/1800	auxiliary power	CCS/IMO TIRE2
KTA19-M	SO40425	237/1600	261/1755	marine propulsion	CCS
KTA19-M	SO40426	258/1600	284/1652	marine propulsion	CCS
K19-M3	SO40433	477/1800		marine propulsion	CCS/IMO TIRE2
K19-DM	SO40434	448/1500	503/1500	auxiliary power	CCS/IMO TIRE2
K19-M	SO40436	373/1800		marine propulsion	CCS/IMO TIRE2
K19-M3	SO40437	447/1800		marine propulsion	CCS/IMO TIRE2
