Cummins KTA19 M3/ KTA19 M600 Marine Engine
- shanghai
- L/C
- 15 days
You May Like
-
Kta38 M1/ Kta38 M1000 Cummins Main Marine Propulsion Diesel Engine
-
Cummins Marine Engine (4BTA3.9 6BTA5.9 6CTA8.3 6LTAA8.9 N855 K19 K38 M11)
-
Cummins Marine Generator 50kVA Ccfj40j
-
Marine Diesel Engine for Cummins 4bt 6bta 6cta
-
Deutz Diesel Engine Bf8l413f Bf8l513
-
Deutz F6l912 Air Cooler Diesel Engine
Product Details
| Brand Name | CUMMINS | Place of Origin | China | |
| Model Number | Cummins KTA19 M3/ KTA19 M600 Marine Engine | Type | Container Ship | |
| Condition | New | Fuel Type | Diesel | |
| Hull Material | IRON | DWT | 10000 - 34999t | |
| Length (m) | < 50m | Year Built | 2022 | |
| TEU | 10 | Draft | 10 |
Product Description
WE can supply CUMMINS KTA19 M3/ KTA19 M600 marine engine
General Engine Data Propulsion Marine Engine Performance Data
ConEngine Model KTA19-M3
Rating Type tinuous Dut
Rated Engine Power kW [HP] 447 [600]
Rated Engine Speed rpm 1800
Rated Power Production Tolerance ± % 3
Rated Engine Torque N@m [lb@ft] 2374 [1751]
Peak Engine Torque @ 1400 rpm N@m [lb@ft] 2680 [1977]
Brake Mean Effective Pressure kPa [psi] 1582 [229]
Indicated Mean Effective Pressure kPa [psi] 1823 [264]
Maximum Allowable Engine Speed rpm N. A.
Maximum Torque Capacity from Front of Crank² N@m [lb@ft] 2374 [1751]
Compression Ratio 13.8: 1
Piston Speed m/sec [ft/min] 9.5 [1875]
Weight (Dry) - Engine Only - Average kg [lb] 2073 [4570]
Weight (Dry) - Engine With Heat Exchanger System - Average kg [lb] 2246 [4952]
NTA855-M SO13458 336KW/1800RPM IMO
NTA855-M SO13497 305KW/1744RPM
NTA855-M SO13510 271KW/1744RPM
NTA855-M SO13520 298KW/2100RPM IMO
NT855-M SO13638 110KW/1600RPM
NT855-M SO13639 140KW/1600RPM
NT855-M SO13640 160KW/1600RPM
NTA855-M SO13649 198KW/1600RPM
NTA855-M SO13650 220KW/1744RPM
NTA855-M SO13660 271KW/1744RPM
NTA855-M SO13662 336KW/2100RPM
NTA855-M SO13710 336KW/2100RPM
NTA855-M SO13711 298KW/1800RPM
N855-M SO13715 298KW/1800RPM IMO2
N855-M SO13716 261KW/1800RPM IMO2
N855-M SO13717 298KW/2100RPM IMO2
NT855-M SO13725 183KW/1744RPM
NTA855-M SO13732 110KW/1600RPM
KTA19-M SO40001 351KW/1800RPM IMO
KTA19-M SO40002 373KW/1800RPM IMO
KT19-M SO40021 317KW/1800RPM IMO
KTA19-M3 SO40028 447KW/1800RPM IMO
KTA19-M SO40036 410KW/2100RPM IMO
KTA19-M3 SO40044 477KW/1800RPM IMO
KTA19-M4 SO40077 522KW/2100RPM IMO
KTA19-M SO40197 351KW/1800RPM IMO
KTA19-M3 SO40200 434KW/1744RPM
KTA19-M3 SO40201 407KW/1744RPM
KTA19-M SO40203 339KW/1744RPM
KTA19-M SO40204 318KW/1744RPM
KT19-M SO40213 288KW/1744RPM
KT19-M SO40301 317KW/1800RPM IMO
KT19-M SO40302 288KW/1744RPM
KTA19-M SO40303 373KW/1800RPM IMO
KTA19-M SO40304 339KW/1744RPM
KTA19-M3 SO40305 407KW/1744RPM
KT19-M SO40336 373KW/1800RPM IMO
KTA19-M SO40366 339KW/1700RPM
KTA19-M3 SO40370 447KW/1800RPM IMO
KTA19-M3 SO40372 447KW/1800RPM BV
KTA19-M SO40373 258KW/1600RPM
KTA19-M SO40374 237KW/1600RPM
KTA19-M3 SO40379 373KW/1800RPM IMO
KT19-M SO40381 193KW/1600RPM
KTA19-M SO40382 373KW/1800RPM BV
KT19-M SO40397 220KW/1744RPM
KT19-M SO40398 203KW/1600RPM
KTA19-M SO40405 300KW/1744RPM
KTA19-M SO40406 288KW/1744RPM
KTA19-M SO40407 265KW/1744RPM
KTA19-M SO40413 373KW/1800RPM
K19-M SO40415 373KW/1800RPM IMO2
K19-M SO40416 410KW/2100RPM IMO2
K19-M SO40417 447KW/1800RPM IMO2
K19-M SO40418 477KW/1800RPM IMO2
KTA19-M SO40425 237KW/1600RPM
KTA19-M SO40426 258KW/1600RPM
K19-M SO40433 477KW/1800RPM IMO2
K19-M SO40436 373KW/1800RPM IMO2
K19-M SO40437 447KW/1800RPM IMO2
KT38-M SO60008 596KW/1800RPM IMO
KTA38-M0 SO60135 671KW/1800RPM IMO
KT38-M SO60137 543KW/1744RPM
KTA38-M1 SO60155 746KW/1800RPM IMO
KT38-M SO60170 582KW/1800RPM IMO
KTA38-M2 SO60180 895KW/1800RPM IMO
KT38-M SO60186 407KW/1744RPM
KTA38-M2 SO60240 895KW/1800RPM BV
KTA38-M1 SO60243 746KW/1800RPM
KT38-M SO60266 440KW/2100RPM
KTA38-M2 SO60270 895KW/1800RPM
KTA38-M2 SO60285 895KW/1800RPM BV
KTA38-M2 SO60287 407KW/1600RPM
KT38-M SO60288 350KW/1600RPM
K38-M SO60293 1007KW/1900RPM IMO2
K38-M SO60294 895KW/1800RPM IMO2
K38-M SO60298 671KW/1600RPM IMO2
K38-M SO60300 1007KW/1900RPM IMO2
K38-M SO60301 970KW/1800RPM IMO2
K38-M SO60302 560KW/1600RPM IMO2
K38-M SO60303 596KW/1800RPM IMO2
K38-M SO60304 634KW/1800RPM IMO2
K38-M SO60305 746KW/1800RPM IMO2
K38-M SO60306 821KW/1800RPM IMO2
K38-M SO60307 821KW/1800RPM IMO2
K38-M SO60308 969KW/1800RPM IMO2
| KT19-M | KT19-M425 | 386/1744 | 425/1800 |
| KT19-M425 | 386/1744 | 425/1800 | |
| KTA19-M | KTA19-M470 | 427/1744 | 470/1800 |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M550 | 500/2027 | 550/2100 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M470 | 427/1744 | 470/1800 | |
| KTA19-M550 | 500/2027 | 550/2100 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M470 | 427/1744 | 470/1800 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M3 | KTA19-M640 | 582/1744 | 640/1800 |
| KTA19-M600 | 545/1744 | 600/1800 | |
| KTA19-M600 | 545/1744 | 600/1800 | |
| KTA19-M600 | 545/1744 | 600/1800 | |
| KTA19-M4 | KTA19-M700 | 636/1744 | 700/1800 |
| KTA19-M700 | 636/2027 | 700/2100 |
| MODEL | SO NO. | RATED POWER kw/RPM | MAX POWER kw/RPM | APPLICATION | CERTIFICATE |
| KTA19-M | SO40001 | 351/1800 | marine propulsion | CCS/IMO | |
| KTA19-M | SO40002 | 373/1800 | marine propulsion | CCS/IMO | |
| KTA19-D(M) | SO40008 | 336/1500 | auxiliary power | CCS/IMO | |
| KT19-M | SO40021 | 317/1800 | marine propulsion | CCS/IMO | |
| KTA19-M3 | SO40028 | 447/1800 | marine propulsion | CCS/IMO | |
| KTA19-M | SO40036 | 410/2100 | marine propulsion | CCS/IMO | |
| KTA19-D(M) | SO40038 | 448/1500 | auxiliary power | CCS/IMO | |
| KTA19-M3 | SO40044 | 477/1800 | marine propulsion | CCS/IMO | |
| KTA19-M4 | SO40077 | 522/2100 | marine propulsion | CCS/IMO | |
| KTA19-D(M) | SO40163 | 448/1500 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40168 | 392/1800 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40185 | 336/1500 | auxiliary power | CCS/IMO | |
| KTA19-M | SO40197 | 351/1800 | marine propulsion | CCS/IMO | |
| KTA19-M3 | SO40200 | 434/1744 | 477/1800 | marine propulsion | CCS |
| KTA19-M3 | SO40201 | 407/1744 | 447/1800 | marine propulsion | CCS |
| KTA19-M | SO40203 | 339/1744 | 373/1800 | marine propulsion | CCS |
| KTA19-M | SO40204 | 318/1744 | 351/1800 | marine propulsion | CCS |
| KT19-M | SO40213 | 288/1744 | 317/1800 | marine propulsion | CCS |
| KTA19-D(M) | SO40249 | 403/1500 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40257 | 463/1800 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40259 | 336/1500 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40260 | 403/1500 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40261 | 448/1500 | auxiliary power | CCS/IMO | |
| KTA19-D(M) | SO40274 | 507/1800 | auxiliary power | CCS/IMO | |
| KT19-M | SO40301 | 317/1800 | marine propulsion | CCS/IMO | |
| KT19-M | SO40302 | 288/1744 | 317/1800 | marine propulsion | CCS |
| KTA19-M | SO40303 | 373/1800 | marine propulsion | CCS/IMO | |
| KTA19-M | SO40304 | 339/1744 | 373/1800 | marine propulsion | CCS |
| KTA19-M3 | SO40305 | 407/1744 | 447/1800 | marine propulsion | CCS |
| KT19-M | SO40336 | 373/1800 | marine propulsion | CCS/IMO | |
| KTA19-D(M) | SO40350 | 392/1800 | auxiliary power | BV Class | |
| KTA19-D(M) | SO40351 | 336/1500 | auxiliary power | BV Class | |
| KTA19-D(M) | SO40353 | 463/1800 | auxiliary power | NK | |
| KTA19-D(M) | SO40354 | 448/1500 | auxiliary power | BV Class | |
| KTA19-D(M) | SO40356 | 463/1800 | auxiliary power | BV Class | |
| KTA19-D(M) | SO40364 | 448/1500 | auxiliary power | BV Class | |
| KTA19-D(M) | SO40365 | 507/1800 | auxiliary power | BV Class | |
| KTA19-M | SO40366 | 339/1700 | 373/1755 | marine propulsion | CCS |
| KTA19-M3 | SO40370 | 447/1800 | marine propulsion | CCS/IMO | |
| KTA19-M3 | SO40372 | 447/1800 | marine propulsion | BV Class | |
| KTA19-M | SO40373 | 258/1600 | 284/1652 | marine propulsion | CCS |
| KTA19-M | SO40374 | 237/1600 | 261/1652 | marine propulsion | CCS |
| KTA19-M3 | SO40379 | 373/1800 | marine propulsion | CCS/IMO | |
| KT19-M | SO40381 | 193/1600 | 212/1652 | marine propulsion | CCS |
| KTA19-M | SO40382 | 373/1800 | marine propulsion | BV Class | |
| KT19-M | SO40397 | 220/1744 | 242/1800 | marine propulsion | CCS |
| KT19-M | SO40398 | 203/1600 | 223/1652 | marine propulsion | CCS |
| KTA19-M | SO40405 | 300/1744 | 330/1800 | marine propulsion | CCS |
| KTA19-M | SO40406 | 288/1744 | 317/1800 | marine propulsion | CCS |
| KTA19-M | SO40407 | 265/1744 | 292/1800 | marine propulsion | CCS |
| KTA19-D(M) | SO40412 | 463/1800 | auxiliary power | CCS/IMO | |
| KTA19-M | SO40413 | 373/1800 | marine propulsion | CCS | |
| K19-M | SO40415 | 373/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K19-M | SO40416 | 410/2100 | marine propulsion | CCS/IMO TIRE2 | |
| K19-M3 | SO40417 | 447/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K19-M3 | SO40418 | 477/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K19-DM | SO40419 | 448/1500 | 503/1500 | auxiliary power | CCS/IMO TIRE2 |
| K19-DM | SO40420 | 507/1800 | 563/1800 | auxiliary power | CCS/IMO TIRE2 |
| K19-DM | SO40421 | 358/1500 | 395/1500 | auxiliary power | CCS/IMO TIRE2 |
| K19-DM | SO40422 | 410/1500 | 451/1500 | auxiliary power | CCS/IMO TIRE2 |
| K19-DM | SO40423 | 425/1800 | 470/1800 | auxiliary power | CCS/IMO TIRE2 |
| K19-DM | SO40424 | 485/1800 | 533/1800 | auxiliary power | CCS/IMO TIRE2 |
| KTA19-M | SO40425 | 237/1600 | 261/1755 | marine propulsion | CCS |
| KTA19-M | SO40426 | 258/1600 | 284/1652 | marine propulsion | CCS |
| K19-M3 | SO40433 | 477/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K19-DM | SO40434 | 448/1500 | 503/1500 | auxiliary power | CCS/IMO TIRE2 |
| K19-M | SO40436 | 373/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K19-M3 | SO40437 | 447/1800 | marine propulsion | CCS/IMO TIRE2 |
Contact Us
- Shanghai DCM Diesel Engine Co., Ltd
- Contact nameDCM INDUSTRY Chat Now
- Phone86-135-64760257
Product Categories
| CUMMINS ENGINE | Deutz air cooler diesel engine | MTU engine parts |
New Products
-
F2l912 F3l912 F4l912 F6l912 Bf6l913c Bf4l913 Deutz Engine
-
12V396TB93 Navy Diesel Motor
-
Fuel Filter 0010920301 H34wk
-
0040175021 NOZZLE HOLDER
-
MTU ENGINE PARTS O-RING 0049976548
-
Grooved Ball Bearing0059812225
Popular Searches
- marine equipment
- gasoline engine
- cummins diesel engine
- fishing boat
- power generator
- propeller shaft
- marine diesel engine
- water cooled diesel engine
- boat engine
- outboard engine
- marine propeller
- outboard motor
- propeller
- marine anchor
- dongfeng diesel engine
- ship engine
- boat motor
- cummins marine engine
- marine power
- boat propeller
- marine boat engine
- boat diesel engine
- pump engine
- cummins marine diesel engine
- marine propulsion engine
- agricultural machinery
- construction equipment
- auto engine
- cummins diesel engine
- wheel loader
Recommended Products
- Qingdao FBA First-leg Transportation to the United States DDP Door-to-door Sea and Air Freight
- International Cargo, Customs Clearance
- Qingdao FBA First-leg Transportation to the United States DDP Door-to-door Sea and Air Freight
- Qingdao FBA First-leg Transportation to the United States DDP Door-to-door Sea and Air Freight
- Qingdao FBA First-leg Transportation to the United States DDP Door-to-door Sea and Air Freight
- International Cargo, Customs Clearance
- FBA First-leg Transportation to the United States DDP Door-to-door Sea and Air Freight
- International Cargo, Customs Clearance
- International Cargo, Customs Clearance
- International Cargo, Customs Clearance
- International Cargo, Customs Clearance
- International Cargo, Customs Clearance
Find Similar Products By Category
- Transportation > Boats & Ships > Cargo Ship
Product Tags:
Shanghai DCM Diesel Engine Co., Ltd
Business license
- Please Enter your Email Address
- Please enter the content for your inquiry.
We will find the most reliable suppliers for you according to your description.
Send Now-
DCM INDUSTRY
Hi there! Welcome to my shop. Let me know if you have any questions.
Your message has exceeded the limit.
- Contact supplier for lowest price
- Customized Request
- Request Sample
- Request Free Catalogs
Your message has exceeded the limit.
-
Purchase Quantity
-
*Sourcing Details
Your inquiry content must be between 10 to 5000 characters.
-
*Email
Please enter Your valid email address.
-
Mobile
