Kta38 M1/ Kta38 M1000 Cummins Main Marine Propulsion Diesel Engine
- shanghai
- T/T
- 15 days
You May Like
Product Details
| Brand Name | CUMMINS | Place of Origin | China | |
| Model Number | Kta38 M1/ Kta38 M1000 Cummins Main Marine Propulsion Diesel Engine | Type | Container Ship | |
| Condition | New | Fuel Type | Diesel | |
| Hull Material | IRON | DWT | 10000 - 34999t | |
| Length (m) | < 50m | Year Built | 2022 | |
| TEU | 10 | Draft | 10 |
Product Description
Kta38 M1/ Kta38 M1000 CUMMINS MAIN MARINE propulsion diesel engine
WE CAN SUPPLY CUMMINS KTA38 M1/ KTA38 M1000 marine engine
Cummins marine engine KTA38 M1000
Displacement: 37 7 liter [2301 in³ ] Rated Power: 746 kw [1000 bhp]
Bore: 159 mm [6 25 in] Rated Speed: 1800 rpm
Stroke: 159 mm [6 25 in] Rating Type: Continuous Duty
Fuel System: PT Aspiration: Turbocharged / Jacket Water Aftercooled
Cylinders: 12
Engine Model KTA38 M1 / KTA38 M1000
Rating Type Continuous Duty
Rated Engine Power kW [HP] 746 [1000]
Rated Engine Speed rpm 1800
Rated Power Production Tolerance ± % 3
Rated Engine Torque N@m [lb@ft] 3956 [2918]
Peak Engine Torque @ 1400 rpm N@m [lb@ft] 4188 [3089]
Brake Mean Effective Pressure kPa [psi] 1318 [191]
Indicated Mean Effective Pressure kPa [psi] N A [N A ]
Maximum Allowable Engine Speed rpm 2375
Maximum Torque Capacity from Front of Crank² N@m [lb@ft] 4341 [3202]
Compression Ratio 13 9: 1
Piston Speed m/sec [ft/min] 9 5 [1875]
Weight (Dry) - Engine With Heat Exchanger System - Average kg [lb] 4538 [10005]
Engine model Max Power (KW) Max Power (HP) Max Speed
NTA855-M SO13458 336KW/1800RPM IMO
NTA855-M SO13497 305KW/1744RPM
NTA855-M SO13510 271KW/1744RPM
NTA855-M SO13520 298KW/2100RPM IMO
NT855-M SO13638 110KW/1600RPM
NT855-M SO13639 140KW/1600RPM
NT855-M SO13640 160KW/1600RPM
NTA855-M SO13649 198KW/1600RPM
NTA855-M SO13650 220KW/1744RPM
NTA855-M SO13660 271KW/1744RPM
NTA855-M SO13662 336KW/2100RPM
NTA855-M SO13710 336KW/2100RPM
NTA855-M SO13711 298KW/1800RPM
N855-M SO13715 298KW/1800RPM IMO2
N855-M SO13716 261KW/1800RPM IMO2
N855-M SO13717 298KW/2100RPM IMO2
NT855-M SO13725 183KW/1744RPM
NTA855-M SO13732 110KW/1600RPM
KTA19-M SO40001 351KW/1800RPM IMO
KTA19-M SO40002 373KW/1800RPM IMO
KT19-M SO40021 317KW/1800RPM IMO
KTA19-M3 SO40028 447KW/1800RPM IMO
KTA19-M SO40036 410KW/2100RPM IMO
KTA19-M3 SO40044 477KW/1800RPM IMO
KTA19-M4 SO40077 522KW/2100RPM IMO
KTA19-M SO40197 351KW/1800RPM IMO
KTA19-M3 SO40200 434KW/1744RPM
KTA19-M3 SO40201 407KW/1744RPM
KTA19-M SO40203 339KW/1744RPM
KTA19-M SO40204 318KW/1744RPM
KT19-M SO40213 288KW/1744RPM
KT19-M SO40301 317KW/1800RPM IMO
KT19-M SO40302 288KW/1744RPM
KTA19-M SO40303 373KW/1800RPM IMO
KTA19-M SO40304 339KW/1744RPM
KTA19-M3 SO40305 407KW/1744RPM
KT19-M SO40336 373KW/1800RPM IMO
KTA19-M SO40366 339KW/1700RPM
KTA19-M3 SO40370 447KW/1800RPM IMO
KTA19-M3 SO40372 447KW/1800RPM BV
KTA19-M SO40373 258KW/1600RPM
KTA19-M SO40374 237KW/1600RPM
KTA19-M3 SO40379 373KW/1800RPM IMO
KT19-M SO40381 193KW/1600RPM
KTA19-M SO40382 373KW/1800RPM BV
KT19-M SO40397 220KW/1744RPM
KT19-M SO40398 203KW/1600RPM
KTA19-M SO40405 300KW/1744RPM
KTA19-M SO40406 288KW/1744RPM
KTA19-M SO40407 265KW/1744RPM
KTA19-M SO40413 373KW/1800RPM
K19-M SO40415 373KW/1800RPM IMO2
K19-M SO40416 410KW/2100RPM IMO2
K19-M SO40417 447KW/1800RPM IMO2
K19-M SO40418 477KW/1800RPM IMO2
KTA19-M SO40425 237KW/1600RPM
KTA19-M SO40426 258KW/1600RPM
K19-M SO40433 477KW/1800RPM IMO2
K19-M SO40436 373KW/1800RPM IMO2
K19-M SO40437 447KW/1800RPM IMO2
KT38-M SO60008 596KW/1800RPM IMO
KTA38-M0 SO60135 671KW/1800RPM IMO
KT38-M SO60137 543KW/1744RPM
KTA38-M1 SO60155 746KW/1800RPM IMO
KT38-M SO60170 582KW/1800RPM IMO
KTA38-M2 SO60180 895KW/1800RPM IMO
KT38-M SO60186 407KW/1744RPM
KTA38-M2 SO60240 895KW/1800RPM BV
KTA38-M1 SO60243 746KW/1800RPM
KT38-M SO60266 440KW/2100RPM
KTA38-M2 SO60270 895KW/1800RPM
KTA38-M2 SO60285 895KW/1800RPM BV
KTA38-M2 SO60287 407KW/1600RPM
KT38-M SO60288 350KW/1600RPM
K38-M SO60293 1007KW/1900RPM IMO2
K38-M SO60294 895KW/1800RPM IMO2
K38-M SO60298 671KW/1600RPM IMO2
K38-M SO60300 1007KW/1900RPM IMO2
K38-M SO60301 970KW/1800RPM IMO2
K38-M SO60302 560KW/1600RPM IMO2
K38-M SO60303 596KW/1800RPM IMO2
K38-M SO60304 634KW/1800RPM IMO2
K38-M SO60305 746KW/1800RPM IMO2
K38-M SO60306 821KW/1800RPM IMO2
K38-M SO60307 821KW/1800RPM IMO2
K38-M SO60308 969KW/1800RPM IMO2
| KT19-M | KT19-M425 | 386/1744 | 425/1800 |
| KT19-M425 | 386/1744 | 425/1800 | |
| KTA19-M | KTA19-M470 | 427/1744 | 470/1800 |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M550 | 500/2027 | 550/2100 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M470 | 427/1744 | 470/1800 | |
| KTA19-M550 | 500/2027 | 550/2100 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M470 | 427/1744 | 470/1800 | |
| KTA19-M500 | 455/1744 | 500/1800 | |
| KTA19-M3 | KTA19-M640 | 582/1744 | 640/1800 |
| KTA19-M600 | 545/1744 | 600/1800 | |
| KTA19-M600 | 545/1744 | 600/1800 | |
| KTA19-M600 | 545/1744 | 600/1800 | |
| KTA19-M4 | KTA19-M700 | 636/1744 | 700/1800 |
| KTA19-M700 | 636/2027 | 700/2100 |
| KT38-M | SO60008 | 596/1800 | marine propulsion | CCS/IMO | |
| KTA38-D(M) | SO60067 | 664/1500 | auxiliary power | CCS/IMO | |
| KT38-D(M) | SO60116 | 560/1500 | auxiliary power | CCS/IMO | |
| KTA38-D(M) | SO60117 | 664/1500 | auxiliary power | CCS/IMO | |
| KT38-D(M) | SO60132 | 560/1500 | auxiliary power | CCS/IMO | |
| KTA38-M0 | SO60135 | 671/1800 | marine propulsion | CCS/IMO | |
| KT38-M0 | SO60137 | 543/1744 | 597/1800 | marine propulsion | CCS |
| KTA38-M1 | SO60155 | 746/1800 | marine propulsion | CCS/IMO | |
| KTA38-D(M) | SO60164 | 880/1500 | auxiliary power | CCS/IMO | |
| KT38-M | SO60170 | 582/1800 | marine propulsion | CCS/IMO | |
| KT38-D(M) | SO60173 | 679/1800 | auxiliary power | CCS/IMO | |
| KTA38-D(M) | SO60174 | 1007/1800 | auxiliary power | CCS/IMO | |
| KTA38-D(M) | SO60175 | 809/1800 | auxiliary power | CCS/IMO | |
| KT38-D(M) | SO60176 | 560/1500 | auxiliary power | CCS/IMO | |
| KTA38-D(M) | SO60177 | 664/1500 | auxiliary power | CCS/IMO | |
| KTA38-D(M) | SO60178 | 814/1500 | auxiliary power | CCS/IMO | |
| KTA38-D(M) | SO60179 | 880/1500 | auxiliary power | CCS/IMO | |
| KTA38-M2 | SO60180 | 895/1800 | marine propulsion | CCS/IMO | |
| KT38-M | SO60186 | 407/1744 | 448/1800 | marine propulsion | CCS |
| KTA38-D(M) | SO60232 | 664/1500 | auxiliary power | BV Class | |
| KTA38-D(M) | SO60236 | 880/1500 | auxiliary power | BV Class | |
| KTA38-M2 | SO60240 | 895/1800 | marine propulsion | BV Class | |
| KTA38-M1 | SO60243 | 746/1800 | 821/1858 | marine propulsion | CCS |
| KT38-D(M) | SO60245 | 679/1800 | auxiliary power | BV Class | |
| KT38-D(M) | SO60246 | 560/1500 | auxiliary power | BV Class | |
| KT38-M | SO60266 | 440/2027 | 484/2100 | marine propulsion | CCS |
| KTA38-M2 | SO60270 | 895/1800 | 985/1858 | marine propulsion | CCS |
| KT38-D(M) | SO60280 | 679/1800 | auxiliary power | CCS/IMO | |
| KTA38-M2 | SO60285 | 895/1800 | marine propulsion | BV Class | |
| KTA38-M2 | SO60287 | 407/1600 | 448/1652 | marine propulsion | CCS |
| KT38-M | SO60288 | 350/1600 | 385/1652 | marine propulsion | CCS |
| K38-DM | SO60289 | 746/1500 | 821/1500 | auxiliary power | CCS/IMO TIRE2 |
| K38-DM | SO60290 | 821/1800 | 903/1800 | auxiliary power | CCS/IMO TIRE2 |
| K38-DM | SO60291 | 880/1500 | 970/1500 | auxiliary power | CCS/IMO TIRE2 |
| K38-DM | SO60292 | 970/1800 | 1067/1800 | auxiliary power | CCS/IMO TIRE2 |
| K38-M | SO60293 | 1007/1900 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60294 | 895/1800 | marine propulsion | CCS/IMO TIRE2 | |
| KTA38-D(M) | SO60296 | 1007/1800 | auxiliary power | CCS/IMO | |
| K38-M | SO60298 | 671/1600 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60300 | 1007/1900 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60301 | 970/1800 | 1067/1800 | marine propulsion | CCS/IMO TIRE2 |
| K38-M | SO60302 | 560/1600 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60303 | 596/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60304 | 634/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60305 | 746/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60306 | 821/1800 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60307 | 821/1801 | marine propulsion | CCS/IMO TIRE2 | |
| K38-M | SO60308 | 969/1800 | marine propulsion | CCS/IMO TIRE2 |
