Mitsubishi Servo MotorHG-JR22K1M

Mitsubishi servo motor HG-JR22K1M Product Specifications

[Applicable Series] MR-J4 Series

[Command interface] CC-Link IE field network interface, SSCNET III/H interface, general interface

[Voltage level] 200V

[Capacity of power supply equipment] 33kVA

[Continuous characteristics] Rated output 22kW, rated torque 140N · m

[Maximum torque] 420N · m

[Rated speed] 1500 r/min

[Maximum rotation speed] 2500 r/min

[Instantaneous allowable rotation speed] 2875 r/min

[Power ratio at continuous rated torque] 401kW/s

[Rated current] 99A

[Maximum current] 315A

[Regenerative braking frequency] 104 rounds/minute

[Inertia J] 489

[Recommended load inertia ratio] below 10 times

[Speed and position detector] Absolute position and increment shared 22 bit encoder (resolution per revolution of servo motor: 4194304pulses/rev)

[Oil seal] Yes

[Heat resistant glass] 155 (F)

[Vibration level] V10

[Allowable load of shaft] L 116mm, radial 2940N, axial 980N

[Weight] 120kg

[Cooling fan]

. Power supply

Voltage | Frequency: three-phase AC200V~230V, 50Hz/60Hz

Input: 60W (50Hz), 80W (60Hz)

Rated current: 0.2A (50Hz), 0.27A (60Hz)
