M7132 Surface Grinder Machine for Metal Grinding
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
M3060A 300mm x 600 mm Promotion Sale Flat Grinder Precision Hydraulic Surface Grinding MachineNegotiableMOQ: 1 -
M618A Surface Grinding Machine With CE StandardNegotiableMOQ: 1
-
M7140 Benchtop Surface Grinder With China PriceNegotiableMOQ: 1
-
MQ6025A Universal Tool Grinder for Metal WorkingNegotiableMOQ: 1
-
M20A Mini Size Grinding Machine Precision Universal Tool Grinder Small Polishing MachineNegotiableMOQ: 1
Product Description
Surface grinding machine
M7135 is used to produce a smooth finish on flat surfaces. It is a widely used abrasive machining process in which a spinning
wheel covered in rough particles cuts chips of metallic or nonmetallic substances from a workpiece, making a face of it flat or
smooth.
M7135 is used to produce a smooth finish on flat surfaces. It is a widely used abrasive machining process in which a spinning
wheel covered in rough particles cuts chips of metallic or nonmetallic substances from a workpiece, making a face of it flat or
smooth.
Main Technical Data
Specification |
M7132 |
||
Worktable size(LxW) |
1000/1400/1600/2000x320mm |
||
Maximum table longitudinal movment |
1100mm |
||
Distance from table to wheel spindle center |
575mm |
||
Max .lateral displacement of the grinding head |
450mm |
||
Grinding head vertical feed per revolution |
1mm |
||
Grinding head vertical feed per grid |
0.01mm |
||
Fast lifting motor
|
Power |
0.37KW |
|
Speed |
1440rpm/min |
||
Wheel size( Dia. x width x bore) |
φ350x40x127mm |
||
Spindle speed |
1440rpm/min |
||
Spindle motor |
7.5KW |
||
The mechanical surface of the base of parallelism |
300/0.004mm |
||
Surface roughness |
Ra:0.63μm |
||
N.W/ G.W |
3800/4400KG |
||
Packing size |
2700x1640x2100mm |
||
Machine details：
