MY1022 Hydraulic Surface Grinding Machine With China Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Machine Grinder MY1224 for Precision Metal GrindingNegotiableMOQ: 1 -
M820 Manual Surface Grinding Machine for Metal WorkNegotiableMOQ: 1
-
Grinding Machines M618 6'' x 18'' Manual Surface Grinding Machine for Metal With CE StandardNegotiableMOQ: 1
-
MY820 Precision Surface Grinding Machine With CENegotiableMOQ: 1
-
Hydraulic Surface Grinding Machine MY1230AHDNegotiableMOQ: 1
Specification |
MY1022 |
MY1224 |
||
Max workpiece to be ground |
540x250mm |
600x300mm |
||
Max travel of table |
560x260mm |
640x320mm |
||
Table max cutting area |
540x250mm |
640x320mm |
||
T-slot (number width) |
1x14 |
1x14mm |
||
Distance from table to spindle center |
450mm |
490mm |
||
Wheel size (dia width bore) |
200x20x31.75 |
250x25.4x76.2mm |
||
Spindle speed |
2850r/m |
1440r/m |
||
Table longitudinal (left and right) speed |
3-20m/min |
3-20/min |
||
Horizontal table (before and after) the amount of feed |
Continuous (variable speed) |
150mm/min |
150mm/min |
|
Intermittent (stepless) |
0-5 |
0-5 |
||
The handlewheel rotates |
450mm |
4mm |
||
Hand wheel each grid |
0.02mm |
0.02mm |
||
Vertical (up and down) feed wheel feed |
The handlewheel rotates |
2mm |
2mm |
|
Hand wheel each grid |
0.01mm |
0.01mm |
||
Spindle motor |
1.5KW |
2.2kw |
||
Cooling motor |
40W |
40w |
||
Hydraulic motor |
1.5KW |
1.5kw |
||
Working pressure |
3Mpa |
3mpa |
||
Oil tank capacity |
80L |
80L |
||
Max flow capacity |
18L/min |
18L/min |
||
The mechanical surface of the base of parallelism |
300/0.004mm |
300/0.004mm |
||
Surface roughness |
Ra0.32 |
Ra0.32um |
||
N.W |
1250kgs |
1500kgs |
||
G.W |
1350kgs |
1650kgs |
||
