table milling machine Swivel Head Knee Milling Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
table milling machine ZAY7045V Variable Speed Milling Machine for Metal Working
-
table milling machine ZX32G hot sales vertical combination drilling and milling machine
-
table milling machine ZAY7032G gear-driven type stand drilling and milling machine with swivel head
-
table milling machine ZAY7045M universal milling machine price with rotary worktable
-
table milling machine ZAY7045FG/1 AUTO FEEDING MILLING AND DRILLING MACHINE
-
table milling machine ZAY7013V drilling and milling for hobby user from China
Product Description
Products Description
XQ6432A,XQ6432C Machine Features:
1. Using one servo motor to control work table’s auto feed on XYZ axes, high torque, energy saving and stable.
2. Full set grind gear guarantee low noise and long service life.
3. Max table travel can reach 1000*380*400mm,has advantages on the market.
XQ6432A,XQ6432C Technology Data:
Specifications | Unit | XL6432 | XL6432C | XL6432CL | ||
Table size | mm | 1325×320 | 1600×320 | |||
Table travel (X/Y/Z) | mm | 750/320/460 | 1100/320/450 | 1300/320/450 | ||
Table feed(X/Y/Z) | mm/min | 30~750/20~500/15~375 | ||||
Spindle taper | 7:24 IS050 (H) 7:24 IS040 (V) | |||||
Arm travel | mm | 550 | ||||
Distance between spindle nose and table surface | mm | |||||
196-656 | ||||||
Distance between horizontal nose and table surface | mm | 20-480 | 20-470 | |||
Distance between spindle axis and arm surface | mm | 245 | ||||
Spindle speed range | r.p.m | 12steps 60-1750 (V) 12steps 60-1800 (H) | ||||
T-slots(NO./width/pitch) | mm | 3/18/80 | ||||
Main motor power | Kw | 5.5 (H) 4 (V) | ||||
3 to feed Ac servo motor torque | N.m | 10 | ||||
Overall size | mm | 1800×2100×2000 | 2245×2100×2000 | 2520×2100×2000 | ||
Net weight | kg | 2635 | 2700 | 2750 | ||
Standard Accessories:
Name | Model | Quantity |
Milling arbor | dia. 27 | 1 |
Elevating lift | 1 | |
Draw bar | M16 | 2 |
Double end spanner | S22-24,S17-19,S32-36 | 1 |
Allen key | 5,6,10 | 1 |
QB13 Machine vice | 136mm | 1 |
Nut | M16 | 2 |
Washer | M16 | 2 |
Milling chuck | ISO40 | 1 |
Quality Certificate | 1 | |
Packing list | 1 | |
Operation manual | 1 | |
EP100 series servo driver manual | 1 |
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
