Table Milling Machine X6336U Vertical Universal Milling Drilling Machine Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Radial Drilling Machine Z3063X20/1 Radial Drilling Machine in Drilling MachinesNegotiableMOQ: 1 -
ZN5040A Manual Machine Vertical Drilling Machine With Low PriceNegotiableMOQ: 1
-
Universal Milling X6332WA Manual Milling Machine With CE for SaleNegotiableMOQ: 1
-
Small Milling XL6436CL Milling Machines With CE Made in ChinaNegotiableMOQ: 1
-
XQ6432A High Rigid Metal Universal Milling MachineNegotiableMOQ: 1
Product Description
X6336U Vertical and Horizontal Dual-purpose Metal Milling Machine Main Features:
1. Rotary milling head can reach 45 degrees;
2. Spindle taper: ISO40(V) /ISO50(H);
3. Spindle speeds: (16steps)66-4540rpm(V) / (12steps)60-1800rp(H).
Specification |
X6336U |
Table size |
1320X360mm |
Spindle taper |
ISO40(V) /ISO50(H) |
Distance from spindle to table |
135-635mm |
Distance from horizontal spindle to table |
0-400mm |
Distance from spindle to column |
200-700mm |
Spindle speeds |
(16steps)66-4540rpm(V) (12steps)60-1800rpm(H) |
Spindle travel |
127mm |
Feeding of quill |
(3steps)0.04 0.08 0.15 |
Max drilling capacity of auto-feeding |
15mm |
Rotary milling head (Left/right) |
45 degrees |
Table travel (horizontal/cross/vertical) |
1000X320X450mm |
Feeding range of longitudinal cross travel |
(8steps)22-555mm/min |
X,Y-axis rapid feed speed |
1080mm/min |
Z-axis rapid feed speed |
560mm/min |
Z-axis motor power |
1100W |
Max weight of workpiece |
500kg |
T-slot number /width/distance |
3/18mm/80mm |
Horse power for main motor |
3.75(V)/4.0kw(H) |
X,Y axis driving motor |
1100W |
Overall dimension |
2220x1790x2360mm |
N.W./G.W. |
2400/2550kg |
Detailed Images
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
