Table Milling Machine ZX32G Hot Sales Vertical Combination Drilling and Milling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Table Milling Machine ZAY7032G Gear-driven Type Stand Drilling and Milling Machine With Swivel HeadNegotiableMOQ: 1 -
Table Milling Machine ZAY7045M Universal Milling Machine Price With Rotary WorktableNegotiableMOQ: 1
-
Table Milling Machine ZAY7045FG/1 AUTO FEEDING MILLING AND DRILLING MACHINENegotiableMOQ: 1
-
Table Milling Machine ZAY7013V Drilling and Milling for Hobby User From ChinaNegotiableMOQ: 1
-
Small Milling Manual Universal Bridgeport Milling Machine ZX6350ZA for Metal Milling FunctionNegotiableMOQ: 1
Product Description
Drilling and Milling ZX32G Features:
1. High precision grinding all steel spindle;
2. High strength with square column;
3. Good strength gear grinding, low nosie;
4.Headstock tilts left and right;
5. Wide electrical box, easy operation;
6. High precision manual feeder;
7. Depth ruler, easy operation and read.
Specification |
ZX32G |
ZX32GV |
Max drilling capacity |
32mm |
32mm |
Max tapping capacity |
16mm |
16mm |
Max face milling capacity |
63mm |
63mm |
Table size |
700*180mm |
700*180mm |
Spindle taper |
MT3/R8 |
MT3/R8 |
X-axis travel |
410mm |
350mm |
Y-axis travel |
205mm |
230mm |
Z-axis travel |
310mm |
380mm |
Spindle travel |
85mm |
75mm |
T-slot size |
12mm |
12mm |
Spindle speed range |
95-1420rpm |
92-1420rpm |
Headstock tilt left and right |
90 degree |
90 degree |
Column size |
150×130×690mm |
150×130×690mm |
Base size |
550×340mm |
550×340mm |
Max. distance from spindle center to column |
203mm |
214mm |
Max. distance from spindle center to table |
336mm |
400mm |
Motor power |
750w |
750w |
N.W/G.W |
170/200kgs |
185/215kgs |
Details Images
Package&Delivery
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
