CJM320A Small Lathe Machine Mini Metal Lathe Machine Price With CE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CW61125B Heavy Horizontal Lathe Machine for Metal CuttingNegotiableMOQ: 1 -
CW61160B Heavy Horizontal Lathe Machine for MetalNegotiableMOQ: 1
-
MPV290 High Precision Variable Speed Mini Metal Lathe Machine From ChinaNegotiableMOQ: 1
-
CS6266C Parallel Lathe Manual Lathe With CE for Precision MachiningNegotiableMOQ: 1
-
C5112 Single Column Conventional Vertical Lathe MachineNegotiableMOQ: 1
Product Description
Features:
1. Precision ground and hardened bed ways.
2. The spindle is supported with precision roller bearings.
3. Headstock gears are made of high quality steel, ground and hardened.
4. Easy operating speed change levers.
5. Spindle speed range 60-1600rpm.
6. Two different lengths of bed are available.
7. With or without cabinet according to requirement.
Specification | CJM320A-600/750mm |
Max. swing over bed | 330mm |
Max. swing over cross slide | 220mm |
Max. length of work piece | 600mm/750mm |
Width of bed | 160mm |
Spindle taper and bore | MT5/38mm |
Max.lateral stroke over tool post | 160mm |
Metric pitches range | 0.5-4 mm |
Inch pitches range | 9-40 T.P.I |
Longitudinal-feed range | 0.135-1.80mm/r |
Max. travel of tailstock sleeve | 70 mm |
Tailstock sleeve taper | MT3 |
Spindle speeds range | 60-1650r/min(50hz) |
Motor | 1.1Kw |
NW/GW (without stand) | 280/300kg 320/340Kg |
Packing size (without stand) | 1330x760x720/1550x760x720mm |
Packing size | 1330x760x1370/1550x760x1370mm |
