CK42T 3-Axis Turning Center Cnc Lathe

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Features:

1.Integrated slant bed structure.easy liquid leaking, high rigidity and good operation. 2.High speed at 5000r/min. First-class precision spindle bearing. 3.High precision ball screw Rexroth, fast feeding for high working efficiency. 4.All-closed stainless steel protection, strong liquid protection without any water leak.

5.8-12 position hydraulic turret, easy machining for complex parts.

Specification	CK42T
Max.swing over bed	420mm
Max.swing over cross slide	350mm
Max.maching diameter(disk/rod)	200mm/60mm
Max.length of work piece	380mm
spindle bearing diameter	80mm
Spindle bore diameter	52mm
Spindle nose	A2-5
Spindle speed range	60-5000r/min
Power of the main motor	5.5-7.5kw
Min.input unit	0.0005/0.001mm
Rapid speed	20/20m/min
Hydraulic chuck	6"
Hydraulic station	8
Max .tool shank	20x20mm
Max.dia for boring size	25mm
Quill diameter	80mm
Quill travel	80mm
Packing size	2125x1345x1640mm
N.W/G.W	3400/3800kgs
