lathe machine CK6432 automatic CNC lathe machine with good price and CE
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
WMT CNC lathe CK6132X750 lathe machine from china type cnc automatic lathe
-
Automatic horizontal metal CNC lathe CK6150x750 with high precision from China factory
-
CK61125 Heavy Duty Horizontal CNC Metal Lathe Machine Price
-
Double column vertical lathe machine CK5225 heavy duty vertical manual lathe machine for metal processing
-
SHL400/350 horizontal cnc torno machines slant bed lathe 8-station servo turret
-
CK1120 multi-function swiss type CNC lathe machine with servo motor
Product Description
Product Description
HOT SELL CNC LATHE MACHINE CK6432
Specification | CK6432×500/750mm |
Max.swing over bed | Φ360 mm |
Max.swing over carriage | Φ150 mm |
Distance between centers | 500/750mm |
Spindle bore | 60mm |
Spindle nose | A2-6 |
Rail width | 260mm |
Taper of spindle bore | MT6 |
Chuck | 8" |
Range of speed (Variable) | 150-2500 rpm |
X axis travel | 350mm |
Z axis travel | 500/750mm |
X/Z rapid speed | 4/7m/min |
X/Z screw | 2004/4006 |
Station of toolpost | 4 or 6 or 8 |
Max. section of tool | 20x20mm |
Stroke of tailstock sleeve | 100mm |
Dia./hole of tailstock sleeve | 50mm/MT4 |
Main motor power | 3.7kw |
Coolant pump power | 120w |
Overall dimenstion (L*W*H) | 1740/2000x1210x1650mm |
Packing size (L*W*H) | 1960/2230x1410x1990mm |
NW/GW | 1275/1450kg;1450/1600kgs |
Detailed Images
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
