HMC630D High Precision Single/double Positions Horizontal Machining Center CNC Horizontal Machining Center
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
HMC1000 High Precision CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
-
High Precision HMC500 CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
-
HMC800 High Precision CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
-
HMC630D Hot Sales Heavy Cutting Single Position CNC Horizontal Machining Center With CE
-
HMC630D High Precision CNC Horizontal Machining Center
-
High Precision HMC500 CNC Double Positions Horizontal Machining Center CNC Horizontal Machining Center
Product Description
Product Description
Single/double positions horizontal machining center HMC630D
Main Features:
1. Flexible processing capacity;2. High machining accuracy;
3. High processing productivity;
4. Reduce operator labor;
5. Complex machined parts;
6. Stable processing quality.
Specification | Unit | HMC630D (Inverted T Type) |
Table travel (X,Y,Z) | mm | 1000*800*800 |
Table size | mm | 630*630 |
Max. load of worktable | kg | 1200 |
Worktable indexinging | ° | 1*360 |
Worktable positioning accuracy | arc-sec | 10" |
Worktable re-positioning accuracy | arc-sec | 2" |
Rapid feed speed | m/min | 24/24/24 |
Spindle speed | rpm | 30-3000 |
Torque of spindle | N.m | 660(gear) |
Tool shank type | BT50 | |
Main motor power | kw | 15/18.5 |
Tool magazine capability | qty | 24(Arm Type) |
Tool weight | kg | 25 |
Positioning accuracy (X,Y,Z) | mm | ±0.005 |
Repeat positioning accuracy (X,Y,Z) | mm | ±0.003 |
Machine weight | kg | 13000 |
Detailed Images
Our horizontal machining center HMC500 is well packed into ploywood cases.
