WMTCNC 3 Axis Precision Linear Guide XH7122 CNC Milling Machine With Automatic Tool Changer
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Cnc Milling XK7116 High Spindle Speed 18000rpm Cnc Metal Milling MachineNegotiableMOQ: 1 -
XK7124 Auto Tool Change Cnc Milling Machine 3 Axis Small Milling in SaleNegotiableMOQ: 1
-
XK7114 Mini 3 Axis CNC Milling Machine With CENegotiableMOQ: 1
-
Hot Sale High Precision 3 Axis CNC Milling Machine XH7126 With GSK Controller for Metal WorkingNegotiableMOQ: 1
-
XH7126 Fanuc Control 5 Axis Metal CNC Milling Machines With Tool ChangerNegotiableMOQ: 1
Product Description
3 Axis CNC milling machine XH7122 main features:
1. Small size with strong cutting;
2. Siemens, GSK CNC system available;
3. XYZ servo drive;
4. XYZ linear guideway.
CNC miling machine Specification | XH7122 |
Worktable size(L*W) | 700x210mm |
Max. loading on worktable | 200kgs |
T slot size | 4x14x50mm |
X axis travel | 360mm |
Y axis travel | 260mm |
Z axis travel | 440mm |
Distance from spindle face to table | 75-520mm |
Distance from center to column guide | 295mm |
Spindle speed | 8000rpm |
Spindle taper | BT30 |
Tool magazine capacity | 8pcs 12pcs(optional) |
X/Y/Z axis rapid feed speed | 10mm/min |
Positioning accuracy （X/Y/Z） | ±0.02mm |
Repeatability accuracy （X/Y/Z） | ±0.01mm |
Max. tool size | 60x175mm |
Max. tool weight | 3kgs |
Main motor power (servo) | 2.2/3.7kw |
Main motor torque (servo) | 14/23.7N.m |
Feeding motor power | 1.5kw |
Feeding motor torque | 6N.m |
Weight(N.W/G.W) | 1300kgs |
Dimension(L*W*H) | 1470x1550x2080mm |
Detailed images
Quality Inspection
Company Profile
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
