Product Description
Model:HTPV-04
Name:Automatic Control Wire Tube Bending Testing Machine/Conduit bending testing equipment
Standard:
According to IEC61730-2:2004 standard requirement
Purpose:
modules provided with junction boxes intended for attachment of a permanent wiring system using conduit must provide assurance of the ability of the box construction to withstand load forces which may be applied to the conduit during and after installation
Technical specifications:
1,Controller set frequency range:0~120 Hz
2,When set the frequency is 60HZ, principal axis revolution: 1 rev./min
3,Principal axis revolution :N rev./min=frequency Hz / 60
4,Timing range:1~9999s
5,Use power is single phaseAC220V,Power consumption100W
Conduit outer diameter suitable counterweight table :
|
Conduit outer diameter(mm) |
Suitable counterweight(N) |
|
13 - 25 |
220 |
|
26 - 50 |
330 |
|
51 -100 |
490 |




FQA :
-Can the equipment be customized?
Provide technical specifications and standards, customized
-About warranty?
Our quality is trustworthy, but we promise a one-year warranty.
-Worried not to use?
We will have professional technicians to guide us remotely. If you like, you can also teach on site.
