HTPV-16
name: Damp -heating testing machine (environment chamber)
Damp heating environment chamber testing machine
environment chamber UV Aging Test Chamber PV Damp Heat Tester
Standard:According to IEC61215,UL1703 standard requirement
Purpose:To determine the ability of the module to withstand the effects of long -term penetration of humidity
Technical specifications
|
Test temperature |
85℃±2℃ |
|
Relative humidity |
85%±5% |
|
Temperature fluctuation |
≤±1℃ |
|
Temperature deviation |
≤±1℃ |
|
Temperature uniformity |
≤2℃ |
|
Humidity range |
30~95%RH |
|
Relative humidity deviation |
≤±2.5 %RH(Humidity 75%RH) |
|
Common moisture point |
85℃/85%RH continue time≥1000h 90℃/90%RH continuity≥1000h |
|
control |
Touch screen +PID intelligence |
|
Can placed test modules |
12 PCS |
|
Inner chamber size |
approx 1.5×2.5×1.5m (L*W*H) |
|
Outer chamber size |
approx 2.5×3.0×2.5m (L*W*H) |
|
Inner chamber material |
Stainless steel(SUS #304) |
|
Outer chamber material |
Steel plate baking finish |
|
PID automatic calculus |
|
|
Thermal insulation material |
hard foam and glass wool |
|
Chamber door |
double type |
|
With cut off program memory |
restart after can automatic restart and continue perform program function |
|
Communicate interface |
RS-232 or RS-485 communicate interface |
|
Air supply circulation system |
Motor |
|
Refrigerant |
Environmental protection refrigerant; |
|
condenser |
water-cooled |
|
Interface show |
Touch screen control |
|
Language |
Chinese and English change each other |
|
data acquisition |
Export, view graphic function |
|
Power |
380V 60HZ |
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
