Solar panel Environment climate chamber simulate low temperature testing machine with IEC61215-2:2016 standard
Testing standard
It's conform IEC61215-2:2016 testing standard
Purpose
It’s to determine the ability of the module to withstand thermal mismatch , fatigue and other stresses caused by repeated changes of temperature
The Main Technical Specifications
|
Temperature range |
-40~85℃ |
|
Temperature fluctuation |
≤±1℃ |
|
Temperature deviation |
≤±1℃ |
|
Temperature uniformity |
≤±2℃ |
|
Rise and down speed rate |
satisfy IEC61215 standard requirement |
|
Humidity range |
30~98% RH |
|
Relative humidity deviation |
±3%FS;deviation 85±2%RH,90±2%RH |
|
Humidity fluctuation |
±2%RH |
|
Humidity uniformity |
≤2%RH |
| Testing pv module quantity | 12 PCS |
| PV Module size | 2m×1m (customized) |
|
Inner chamber and outer chamber material |
stainless steel |
|
Control system |
automatic calculus |
|
Display panel |
touch screen |
|
Communicate interface |
RS-485 communicate interface |
|
Electricity |
380V 60HZ |
