KASON Led Light Binocular School Teaching Biological Laboratory Microscope

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

KASON A12.1502-AB Led Light Binocular School Teaching Biological Laboratory Microscope

Product Description

Application:

Differential Interference Contrast Microscope is suitable to observe many different kinds of object. It is equipped with transmitted illuminator and reflected DIC system, infinity plan achromatic objectives with long working distance, wide-field eyepieces and polarizer device. It provides clear and 3D image, beautiful sculpt, convenient control, etc. It is the ideal instruments in research work in biology, metallography, mineralogy, precision engineering, electronics, etc. Features

--DIC, Bright Field/Dark Field, Polarizing Observation Available
--Excellent UIS optical system can obtain excellent optical performance.
--Compact and steady main frame body is embodiment for the shock resistance.
--The large-mobile range mechanical stage is adapted to observation big size specimen or quick check.
--Modularization function design so that update system expediently
--Ideal ergonomic design is adopted in this unit and have easier operation and wider space

Specifications

A12.1502 Laboratory Biological Microscope		B	T	AB	AT
Optical System	Infinity Optical System	o	o
Optical System	Achromatic Optical System			o	o
Head	Binocular, Inclined at 30º, Interpupillary 48-75mm, 360° Rotatable	o		o
Head	Trinocular, Inclined at 30º, Interpupillary 48-75mm, 360° Rotatable		o		o
Eyepiece	WF10x/22mm, Dia.30mm, High Eyepoint, Diopter Adjustment -/+5	o	o
Eyepiece	WF10x/20mm, Dia.30mm, High Eyepoint, Diopter Adjustment -/+5			o	o
Nosepiece	Backward Quadruple Nosepiece	o	o	o	o
Objective	Infinite Plan High Contrast Chromatic-free 4X,10X,40X,100X	o	o
Objective	High Contrast Chromatic-free 4X,10X,40X,100X			o	o
Condenser	Abbe Condenser NA1.25, with Iris Diaphragm, Center Adjustable	o	o	o	o
Focusing	Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm/Rotation, Moving Range 24mm, With Safety Stop Screw, Tension Adjustable	o	o	o	o
Working Stage	Large Size Double Layer Mechanical Stage 216x150mm, Graphite Surface, Moving Range 75mmx55mm, Reckless Safety Round Edge	o	o
Working Stage	Large Size Double Layer Mechanical Stage 142x132mm, Graphite Surface, Moving Range 75mmx50mm			o	o
Light Source	Kohler Illumination, 3W/LED, Brightness Adjustable, With Blue Filter	o	o
Light Source	External Illumination, 3W/LED, Brightness Adjustable, With Blue Filter			o	o
Adapter	C-Mount 1.0x		o		o

Please contact KASON directly for best quotation
