Automatic Roll Paper Sheeting Machine
- T/T Credit Card
You May Like
-
500mm Paper Reel Cutting Machine for A4 Size
-
DP-360 Max Width 360mm Paper Sheeter Machine
-
Customized Roll to Sheet Cutter Machine( Sheet Cutting Machine)
-
Plastic Sheet Cutter Machine ( Sheet Cutting Machine)
-
Rubber Foam Roll to Sheet Cutting Machine( Sheet Cutter)
-
Aluminum Foil Roll Cutting Machine (sheet Cutter)
Product Description
Roll paper sheeting machine
FUNCTIONAL CHARACTERSTICS
This machine employs servo motor to feed material, import PLC touch screen operation to set any length, quantity,
speed and finish singleness cutting , equipped with automatic unwinding system and air shaft,
which will be easy to load and unload.
with photoelectric system to searching the marks , and with the electric static eliminator after cutting the sheets
Purpose
Sizing cutting for all kind paper, aluminum foil, copper foil, PET, PC, PVC, PCB, FPC, Lithium battery film, flannelette, metal foil and all kinds of material in roll form.
| Model | 500mm paper sheeting machine |
| Max Feeding Width ( mm ) | 500 |
| Main Engineer Power ( w ) | 400 |
| Speed ( t/m ) | 110 |
| Size ( mm ) | 1200*900*1280 |
| Weight ( kg ) | 400 |
| Precision ( mm ) | ±0.10 |
| Power | 220V 50HZ |
| shipping Term | FOB Shanghai |
| Shaft diameter | 3 inch / 76mm |
| unwinding paper diameter | 600mm max |
paper sheeting machine
Unwinding:
Cutting and stacking :
Operation board :
Special Unwinding size 1000mm:
the shaft can take off when like this , standard machine no need take off shaft
Pressure adjustment part :
| DP- 500 paper sheeting machine | ||
| Electrical listing : | ||
| Touch Screen | KUNLUN | Made in China |
| Programmable Controller | MITSUBISHI | Made in Japan |
| Servo Driver | DELTA | TAIWAN,CHINA |
| Servo Motor | DELTA | TAIWAN,CHINA |
| Motor of cutting knife | TPG | Made in Japan |
| AC Contactor | RENMIN | Made in China |
| Solid State Relay 20A | Guguang | Made in China |
| Electric eye | Panasonnic | Made in Japan |
HS Code:8441100000
Delivery time : 7 working days after received payment
Terms of payment :100% paid off before shipment ,
seller should offer operation videos of machine to customer
warranty and service plan
12 month after sale Warranty Service (excluding Wear and Tear item )
After-service for paper sheeting machine:
1. Warranty for machine: 12months
2. After-service: A reply within 24 hours
3. A free training in our factory available before delivering machines.
