BNUV-S510 Single Beam UV Visible Spectrophotometer With Touch Screen

BNUV-S510 Single Beam UV Visible Spectrophotometer With Touch Screen thumbnail-1
BNUV-S510 Single Beam UV Visible Spectrophotometer With Touch Screen thumbnail-2
BNUV-S510 Single Beam UV Visible Spectrophotometer With Touch Screen photo-1
BNUV-S510 Single Beam UV Visible Spectrophotometer With Touch Screen photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Contact Supplier Request Quote Chat Now
Hangzhou Boyn Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
Product features: Single beam
4.3 inch touch screen.
Printer interface
Product Paramenters
Model
BNUV-S510
Optical system
Single Beam, holographic grating 1200 lines/mm
Wavelength Range
200-1000 nm
Spectral Bandwidth
4 nm
Wavelength Accuracy
±2.0 nm
Wavelength Repeatability
1.0 nm
Photometric Range
0 ~ 200%T, -0.301 ~ 3.000Abs, -9999 ~ 9999C, -9999 ~ 9999F
Transmittance Accuracy
±0.5 %T
Transmittance Repeatability
0.2 %T
Stray Light
0.5 %T(at 220nm and 360nm)
Baseline Drift
≤0.002 Abs / half hour (after warm-up at 500 nm)
Display Screen
4.3 inch color touch-screen display, LCD
Photometric model
T.A.C
Monochromator
C-T monochromator
Sensor
silicon photocell
Wavelength Calibration
automatic calibration after starting up
Wavelength Resolution
0.1 nm
Light Source
deuterium lamp (1000h), tungsten lamp (2000h, 20W/12V)
Light Switching Point
can be set, 294 nm - 365 nm
Output Interface
USB interface
Sample Holder
4 trench 50mm adjustable sample holder (10mm, 20mm, 30mm, 40mm, 50mm,
position-adjustable)
Sample compartment
10mm pathlength cuvette
PC software
NO
Power
220V 50Hz 90VA / 110V 60Hz 90VA
Overall Dimension
470×380×225mm (L*W*H)
Package Dimension
650×539×370mm (L*W*H)
Net Weight
10.5 Kg
Gross Weight
14.5 Kg
Standard Accessories
Glass cuvette 10mm×4,Quartz Cuvette 10mm×2, Fuse×2, Power cable, User manual
Recommend Products
Company Profile
Why Choose Us
FAQ
What is your minimum order quantity(MOQ)? Our minimum order quantity (MOQ) is generally 1 unit. The exception however is that for certain items (e.g. labware or consumables) the MOQ may vary. How long are your warranty? All BOYN products are warranted to be free from defects in material and workmanship under normal use and service for a period of one (1) year from the date of original installation or 14 months after shipment date from the manufacturer, whichever occurs first. How about the maintenance after the warranty period? After the warranty period, we are still responsible for after-sales service. As long as the useful life of the equipment is unexpired, we will provide paid services for replacement parts. How can I make payment? And what is your payment term? Payment can be made through wire transfer (T/T), letter of credit (L/C at sight), PayPal or Western Union. Our payment term is 100% deposit in advance What is the packaging of your products? We always use high quality corrugated cardboard box or non-fumigation plywood case to pack them, even with inner void fill materials for extra protection. Do you deliver to ...? Yes we do! We deliver worldwide. The available Shipping methods: forwarding agencies by air & by sea & by train, Parcel services by DHL & FEDEX & TNT, or self-pickup. How long does it take to deliver the products after I place an order? Our lead time varies with our current storage and production schedule. Most of products can be delivered within 7-15days after receiving your full payment How long is the validity of quotation? Generally, All Prices quoted by us are valid for 30 days from the date of stated on the quotation. Can you modify your equipment to comply with different voltages power supply and sockets? In most cases yes, we can, but not always. Please contact us for details Who will install the unit in my place? The quotation do not include any installation and training fee. Your engineer should install it by himself with reference of user manual or installation video which provided by us. What if I have an issue with my order? If you have an issue with any of the products or services you have received from us, please contact us as soon as possible by calling +86-153-0652-2608 or contacting your Sales Consultant directly.
