Customized SHACMAN brand 8*4 LHD 14T knuckle crane boom mounted on cargo truck for sale,
Customized SHACMAN brand 8*4 LHD 14T knuckle crane boom mounted on cargo truck adopts Shacman M series low-top luxurious driver cab, 2100+4575+1400mm wheelbase,
SHACMAN brand 8*4 LHD 16T knuckle crane boom mounted on truck for sale, 10JSD180+QH50 gearbox, WP10.380E22 380hp diesel Euro 2 engine, MAN 9.5T front axle, 400L aluminum alloy tanker, 12.00R20 rail tires, etc.
Clients choose to install CLW Brand high quality 30tons knuckle crane boom. The cargo body dimension (L*W*H): 8000x2450x600 (mm). There are rear manual ladders at the rear part of the cargo body. Choosing to install XCMG brand 14T knuckle crane boom (the working height is 14m and the working radius is 12.1m, full rotation with aerial operation seat).
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
More pictures of SHACMAN brand 8*4 LHD 14T cargo truck with crane is as below.
HOT SALE! SHACMAN brand 8*4 LHD 14T knuckle crane mounted on cargo truck
The specification of SHACMAN brand 8*4 LHD 14tons knuckle crane boom mounted on truck as below
Product name |
SHACMAN brand 8*4 LHD 14tons knuckle crane boom mounted on truck for sale |
|
Chassis type |
SX1310 |
|
Parameters |
Overall dimension length/width/height (mm) |
12000×2550×3980 |
Cargo body dimension (L*W*H)(mm) |
8000×2450×600,800 |
|
GVW(kg) |
31000 (Kg) |
|
Kerb Mass(kg) |
20800 (Kg) |
|
Rated mass(kg) |
10070,10005 (Kg) |
|
Approach angle/ Departure angle(mm) |
16/10 (°) |
|
Front suspension/rear suspension(mm) |
1525/2400 |
|
Fuel Type |
diesel |
|
Max Speed |
90 |
|
Engine |
Type |
WP10.380E22 |
Displacement/Power(kw) |
9726ml/280KW/380hp |
|
Manufacturer |
WEICHAI |
|
Chassis |
Drive Type |
8*4 |
Wheelbase(mm) |
2100+4575+1400 |
|
Tread(front/rear) |
2036/2036, 1860/1860 (mm) |
|
Transmission |
10JSD180+QH50 manual gearbox |
|
Braking system |
Air braking |
|
Cab |
SHACMAN M3000 luxurious driver cab |
|
Number of spring axle(front/rear) |
10/10/12 |
|
Tire Type |
12.00R20 |
|
Upper part(cargo van and crane boom) main parameters | ||
Upper body |
Cargo body dimension |
8000x2450x600 |
Material |
Carbon steel |
|
Painting |
Upon request |
|
Crane boom main parameters | ||
Crane boom |
Choose to install CLW brand 14T 5 sections knuckle crane boom |
|
Lifting height |
14m |
|
Working radius |
12.1m |
|
The color of the whole truck is upon request. | ||
The cargo crane is also called truck mounted crane, crane truck, truck with crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional cargo truck crane supplier in China, we Chengli Special Automobile Co., Ltd. manufacture the crane boom is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom truck mounted crane, knuckle boom truck mounted crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane for truck can be crane, chengli crane, sany crane, unic crane, kanglim crane, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us. The hot sale line is 0086 13329899995.
