Vacuum Decompression concentration tank concentrator

FOB Price

USD $5000 - $50000 / Set

1 Set(Min.Order)

Supply Ability 20 Set / Sets per Month
Port Ningbo
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Certification	ISO9001
Warranty	One year after receiving equipment, offer life long after sale service.	Condition	New
Processing Types	Other, liquid materials

Product Description

Vacuum Decompression concentration tank concentrator
Fact part in contact with material is made with stainless steel SUS316L (or SUS304) brings qualified anti-corrosion performance, meeting with the GMP standard
Device is suitable to concentrate in pharmacy, foodstuff, chemistry and also can serve as reclamation of alcohol and simple reflux extraction
Configure:
Concentration tank, condensator, (gas and liquid) separator, cooler and liquid receiving tank.

Condensator type: Tubular type

Finish: Internal Mirror polish

External: Matt GMP standard.

Item/Spec		ZN-50	ZN-100	ZN-200	ZN-300	ZN-500	ZN-700	ZN-1000	ZN-2000
Concentrating capacity(kg/h)		20	40	60	80	100	130	160	350
Steam Pressure(MPa)		0.09
Heating area(m2)		0.4	0.6	0.8	1.1	1.2	2.0	2.5	5.5
Condensing area(m2)		1.2	1.7	2.4	3.0	3.2	3.6	4.5	14
Cooling area(m2)		0.25	0.35	0.45	0.6	0.7	0.85	1.1	3
Receiving tank(L)		15	45	60	76	100	125	140	185
Consumption(kg/h)		23	46	70	92	115	150	185	403
Vacuum Degree(MPa)		-0.08
Equipment type		Normal pressure vessel
Dimension(mm)	L	1200	1350	1700	1800	2100	2400	2490	2730
	W	600	750	800	950	1200	1300	1300	1500
	H	2200	2200	2700	2850	3400	3400	3720	4700
