Centerline of Folder-like Soft Seal Butterfly Valve

US$ 1 - 1000 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Model Number:

D671X-6、D671X-10、D671X16、D971X-6、D971X-10、D971X-116

Material:

Casting

CHY Shanghai Anshu Mechanical&Electrical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

20 days

Place of Origin China

Model Number D671X-6、D671X-10、D671X16、D971X-6、D971X-10、D971X-116

Material Casting

Application General

Structure Butterfly

Standard or Nonstandard Standard

Pressure High Pressure

Power Pneumatic

Media Base

Temperature of Media Medium Temperature

Centerline of folder-like soft seal butterfly valve

DN(mm)	Major Dimensions					Dimensions and specifications flange bolts
	Major Dimensions					0.6MPa		1.0MPa		1.6MPa
	L	E	h2	E	F	D1	n-Φ	D1	n-Φ	D1	n-Φ
50	43	80	160	137	109	110	4-Φ14	120	4-Φ19	125	4-Φ14
65	46	88	175	204	109	130	4-Φ14	136	4-Φ19	145	4-Φ14
80	46	96	180	204	109	150	4-Φ19	160	8-Φ19	160	4-Φ19
100	52	115	200	230	135	170	4-Φ19	185	8-Φ19	180	4-Φ19
125	56	128	213	271	135	200	8-Φ19	215	8-Φ19	210	8-Φ19
150	56	140	225	305	153	225	8-Φ19	238	8-Φ23	240	8-Φ23
200	60	175	260	380	218	280	8-Φ19	295	8-Φ23	295	12-Φ23
250	68	202	290	462	218	335	12-Φ19	357	12-Φ23	355	12-Φ28
300	78	242	330	555	218	395	12-Φ23	407	12-Φ23	410	12-Φ28
350	78	266	360			445	12-Φ23	467	16-Φ23	470	16-Φ28
400	102	298	390			495	16-Φ23	515	16-Φ28	525	16-Φ31
450	114	315	410			550	16-Φ23	565	20-Φ28	585	20-Φ31
500	127	348	430			600	20-Φ23	620	20-Φ24	650	20-M30
600	154	400	490			705	20-Φ26	725	20-Φ27	770	20-M33
700	165	520	550			810	24-Φ26	840	24-Φ27	840	24-M33
800	190	591	610			920	24-Φ31	950	24-Φ30	950	24-M36
900	203	660	680			1020	24-M27	1050	28-M30	1050	28-M36
1000	216	670	730			1120	28-M27	1160	28-M33	1170	28-M39
1200	254	780	835			1340	32-M30	1380	32-M36	1390	32-M45
1400	279	890	935			1560	36-M33	1590	36-M39
1600	318	1000	1035			1760	40-M33	1820	40-M45
