Help CenterHand Sanitizer Filling & Capping Machine Piston Type Quantitative Filling Machine Servo Capping Machine Automatic Following Type Filling Machine
Related Products
-
Manufactory Supply of Automatic Gel Tube Assembly Machine Automatic Gel Tube Sealing MachineCNY 110000 - 130000MOQ: 1 Set -
Automatic Gel Tube and Gel Ice Pack Filling and Sealing MachineCNY 135000 - 150000MOQ: 1 Set
-
Hot Selling FOB Guangzhou Price Full Set Complete Automatic Bottle Liquid Perfume Filling Capping Packing Machine LineCNY 250000 - 270000MOQ: 1 Set
-
High Quality Small Volume Lyophilized Powder/essential Oil Filler Automatic Bottle Filling and Caping Packing Machine LineCNY 85000 - 120000MOQ: 1 Set
-
Automatic Chilli Paste Condiment Seasoning Jam Glass Bottle Liquid Filling Machine Production LineCNY 65000 - 100000MOQ: 1 Set
Doubie Heads Tracking Type Servo Piston Filling Machine Equipment Overview:
Double heads tracking type servo piston filling machine consists of chain conveyor, composed of bottle clamping automatic alignment mechanism, filling mechanism, automatic servo piston system, electric lifting adjustment mechanism, waterproof electric cabinet, touch man-machine operation interface, etc.This machine has the function of one-button quick changeover, which can be applied to the automatic filling equipment for bottles of different specifications.
Technical Parameters
illing heads：2 heads
Filing form:Servo piston type
Filing capacity:500ml~5000ml
Flling accuracy:±1%
Program control：PLC+ touch screen
Material of contact parts：304# stainless steel, PVC
Air pressure：0.6-0.8MPa
Power：About 4kW
Voltage：AC220V 50/60Hz
Conveyor belt：82mm wide POM chain belt, speed 0-15m/min
Conveyor motor：750W frequency control motor
Speed：About 4050 bottles/min
