Filling (rotating) plunge cap press cap 2 in 1 capping machine
Equipment Overview:
This equipment is our company's independent research and development of automatic filling (rotary) plunge cap press cap integrated machine, using gas and electricity as integrated machine with PLC system control, easy to operate. The equipment adopts negative pressure filling, which is the first in China. It can also use peristaltic pump or ceramic pump filling method. The unique plug-in filling valve is unique in China. The equipment has a bottle filling, no bottle stop irrigation. This equipment fills the gap of the domestic small-bore bottle automated production equipment, fully embodies the company's advantages in the design and manufacture of non-standard packaging materials. The equipment fully complies with GMP production specifications. Widely used in perfumes, hair conditioners, oral liquids, essential oils and other products.
Filling plug and capping machine
Technical parameters:
1. Number of filling: 2 Filling form: peristaltic pump filling
2. Filling capacity: 5, 10 ml filling accuracy: ±1%
3. Plug and cover type: electromagnetic plate (different specifications need to replace the plate and guide rail)
4. Suitable bottle type: according to customer samples (chuck needs to be replaced for different bottle types)
5. Number of plug heads: 2 Type of plug: manipulator to take the plug cylinder plug
6. Lower cover form: vibration plate cover, automatic hook cover lower cover
7. Number of servo screw-caps: 2 Screw-caps type: 2 electric servo screw-caps
8. Conveyor belt: 82mm wide POM chain belt, speed 0-15m/min
9. Machine power: about 5KW
10. Program control: PLC with touch screen man-machine interface
11. Material: The frame adopts 304# stainless steel
12. Filling nozzle and other liquid contact parts material: 304# stainless steel, silicone tube
13 air pressure: 0.6-0.8mpa
Power supply: AC220V/380V, 50/60Hz.
