Easy to operate manual weighing and filling machine semi automatic filling machine liquid

5 nozzles weighing filling machine

Equipment Overview:

The automatic weighing filling machine is composed of a dynamic weighing module, a touch screen and a highly automated digital display filling device controlled by PLC system. Filling process, the first fast and then slow filling method, not only improve the output, but also improve the filling accuracy. Simply place the container on the conveyor belt and transport the container to the filling station via the conveyor belt, which automatically Remove the tare weight and automatically fills. This equipment is used together with automatic press plug machine, automatic capping machine, and automatic labeling to compose a production line. It is widely used in daily chemical, chemical and food industries. Such as: Lubricants, car urea, pesticides, liquid fertilizers, syrups, oligofructose and other products.

Technical Parameters:

Filling head number: 5

Filling method: weighing and quantitative filling

Filling capacity: 10~50KG

Filling speed: 500 barrels / hour (20 liters barrel calculation)

Filling accuracy: ±0.5%

Air pressure: 0.6-0.8MPa

Power: 1.5KW/AC220V 50/60HZ
