Automatic 5 Heads Liquid Weighing Filling Machine

Automatic 5 Heads Liquid Weighing Filling Machine photo-1
Automatic 5 Heads Liquid Weighing Filling Machine photo-2
Automatic 5 Heads Liquid Weighing Filling Machine photo-3
Automatic 5 Heads Liquid Weighing Filling Machine photo-4
Automatic 5 Heads Liquid Weighing Filling Machine photo-5
CNY 80000 - 120000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Guanhong Intelligent
Place of Origin:
China
Model Number:
15217238829
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
30 days
Brand Name Guanhong Intelligent
Place of Origin China
Model Number 15217238829
Certification http://gd-guanhong.com/
After-sales Service Provided Engineers available to service machinery overseas
Weight 280KG
Dimension(L*W*H) 2000mm*1500mm*2000mm
Voltage AC220V/380V 50/60Hz
Power about 1.5KW
Application Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Condition New
Automatic Grade Automatic
Driven Type Electric
Packaging Material Glass, Metal, Plastic
Packaging Type Bags, Barrel, Bottles, Cans, Capsule, Cartons, Case, Pouch, Stand-up Pouch





5 nozzles weighing filling machine

Equipment Overview:

The automatic weighing filling machine is composed of a dynamic weighing module, a touch screen and a highly automated digital display filling device controlled by PLC system. Filling process, the first fast and then slow filling method, not only improve the output, but also improve the filling accuracy. Simply place the container on the conveyor belt and transport the container to the filling station via the conveyor belt, which automatically Remove the tare weight and automatically fills. This equipment is used together with automatic press plug machine, automatic capping machine, and automatic labeling to compose a production line. It is widely used in daily chemical, chemical and food industries. Such as: Lubricants, car urea, pesticides, liquid fertilizers, syrups, oligofructose and other products.


Technical Parameters:

Filling head number: 5

Filling method: weighing and quantitative filling

Filling capacity: 10~50KG

Filling speed: 500 barrels / hour (20 liters barrel calculation)

Filling accuracy: ±0.5%

Air pressure: 0.6-0.8MPa

Power: 1.5KW/AC220V 50/60HZ


Product Tags: Automatic 5 heads weighing filling machine , Automatic filling machine , liquid weighing filling machine
