Multi-function Automatic Chuck Type Filling Machine/ Small Bottle Filling Capping and Labeling Machine Production Line

Multi-function Automatic Chuck Type Filling Machine/ Small Bottle Filling Capping and Labeling Machine Production Line photo-1
Multi-function Automatic Chuck Type Filling Machine/ Small Bottle Filling Capping and Labeling Machine Production Line photo-2
Multi-function Automatic Chuck Type Filling Machine/ Small Bottle Filling Capping and Labeling Machine Production Line photo-3
Multi-function Automatic Chuck Type Filling Machine/ Small Bottle Filling Capping and Labeling Machine Production Line photo-4
Multi-function Automatic Chuck Type Filling Machine/ Small Bottle Filling Capping and Labeling Machine Production Line photo-5
CNY 180000 - 280000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Guanhong Intelligent
Place of Origin:
China
Model Number:
15217238829
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
30 days
Brand Name Guanhong Intelligent
Place of Origin China
Model Number 15217238829
Certification http://gd-guanhong.com/
After-sales Service Provided Engineers available to service machinery overseas
Weight 280KG
Dimension(L*W*H) 2000mm*1500mm*2000mm
Voltage AC220V/380V 50/60Hz
Power about 1.5KW
Application Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Condition New
Automatic Grade Automatic
Driven Type Electric
Packaging Material Glass, Metal, Plastic
Packaging Type Bags, Barrel, Bottles, Cans, Capsule, Cartons, Case, Pouch, Stand-up Pouch





Chuck type combination machine

Technical parameters:

1, suitable bottle type: according to customer sample (1 type of tube, 1 type of outer cover)

2. Tube feeding form: manual tube feeding to bottle sorting bucket

3, filling form: peristaltic pump filling

4. Number of filling: 2

5, filling capacity: 10mL

6, filling material: reagent (material above 40 degrees is liquid, below 40 degrees is solid, non-corrosive)

7, the outer cover form: electromagnetic vibration plate (1 out 2)

8, the outer cover form: servo motor cap

9. Capping motor: 400 servo motor

10. Production speed: about 1800 bottles/hour

11, material: the frame adopts 304# stainless steel

12, the machine power: about 4KW

13, program control: PLC+ touch screen

14. Air pressure: 0.6-0.8mpa

Power supply: AC220V/380V, 50/60Hz


Product Tags: automatic small filling machine production line , Multi function automatic chuck type filling machine , liquid filling small bottle filling production line
