Help CenterDW-S410 NIR Spectrometer With High Accuracy
Related Products
-
DW-S410 NIR Spectrometer AnalyzerUS$ 7,800 - 10,000MOQ: 1 Piece -
Atomic Fluorescence Spectrometer Supplier DW-AFS-610EUS$ 8,000 - 12,000MOQ: 1 Piece
-
Integrated AAS With Flame and Graphite FurnaceUS$ 5,000 - 15,000MOQ: 1 Piece
-
Flame Graphite Furnace Integral Atomic Absorption SpectrophotometerUS$ 5,000 - 15,000MOQ: 1 Piece
-
Automated Control AAS With Automatic Graphite Furnace And 6 Lamps TurretUS$ 5,000 - 15,000MOQ: 1 Piece
NIR Spectrophotometer
Model:DW-S410
COMMON FEATURES
Transmission NIR, mainly used for liquid samples qualitative and quantitative analysis, applies to gasoline, drinks, milk and other areas of nutrients, water chemistry and other physical properties of the rapid non-destruc- tive analysis determination.
Single-channel whole spectrum scanning.
CAUNIR NIR analysis software with laptop, full automation, many regular function, spectrum pre-process, model test and distract, self-test correction, sample analysis, scanning curve storage/ display/comparison, print
Quantitive analysis process of gasoline octane value/ antiknock Coefficient /EP value
is very short, gasoline Ron model correlation coefficient≥0.97.
Easily updated. Fast scan, wavelength calibrate time from 900nm to 1700nm less than 2 minutes. Built in SCM technology, auto 0% and auto background subtraction.
|
Wave Length Accuracy |
±1nm |
|
Wave Length Reproducibility |
≤1nm |
|
Scanning Interval |
1nm,4nm,8nm,16 nm |
|
Reproducibility S/N |
≥ 103 (at 1500nm) |
|
Scanning Time |
≤2mins |
|
Application field |
liquid dope samples(gasoline, drink and milk, etc) |
|
Optical system |
grating monochromator |
|
Detector |
InGaAs |
|
Interface |
RS232 serial port |
CAUNIR NIR
ANALYSIS SOFTWARE
|
Application type |
Quantitative or qualitative |
|
Modeling |
Improved PLS,Artifical Neural Networks |
|
Model Transfer |
Slope / Intercept correction,single-sample model transfer,etc |
|
Spectrum pretreatment |
Centricity,First and Second Derivative, Vector Normalization, Additional scatter correction |
STANDARD
ACCESSORIES
|
S410 spectrophotometer |
1 set Power |
|
cable |
1 pc User Manual |
|
1 pc Fuses(2A) |
2pcs |
|
S410 Data processing software package |
1 set |
OPTIONAL
ACCESSORIES
Fuse (2A) Communication cable
