Home > Products > Bare Conductor > Overhead bare 35mm2 50mm2 annealed oxygen-free hard drawn stranded copper conductor
Overhead bare 35mm2 50mm2 annealed oxygen-free hard drawn stranded copper conductor
US$ 3 - 20
/ Meter
100 Meters(Min. Order)
- QingDao(mainly) ShangHai Tianjin
- T/T Credit Card
You May Like
-
Overhead Aluminum Alloy Bare AAAC conductor Cairo
-
ACSR conductor price list All Aluminum Bare Conductor
-
Bare Conductors AAC, AAAC, ACSR Electrical Wire Aerial Overhead Cable Aluminium Copper Wire Cable
-
AAAC 1000mm2 Aluminum Alloy Conductor Cable
-
Overhead Aluminum Alloy Bare AAAC Conductor Oak
-
Overhead BS Standard aluminum dog conductor ACSR 100mm2
Product Details
| Brand Name | RMjT | Place of Origin | Henan, China | |
| Conductor Material | Copper |
Product Description
Product Description
Applications
* Overhead electrical systems
* Mass transit and high speed systems
* Both AC and DC applications
* Specialized applications for Tin and Silver Copper Alloys
* Light Rail, tram and trolley bus systems
* Overhead traveling cranes
* Overhead electrical systems
* Mass transit and high speed systems
* Both AC and DC applications
* Specialized applications for Tin and Silver Copper Alloys
* Light Rail, tram and trolley bus systems
* Overhead traveling cranes
* others
Manufacturing Standards
We can supply this conductor according to different recognized standards,such as
GB/T,IEC,ASTM,CSA,BS,DIN,AS,JIS,KS,NFC and so on.Customer special specification
also can be satisfied.
We can supply this conductor according to different recognized standards,such as
GB/T,IEC,ASTM,CSA,BS,DIN,AS,JIS,KS,NFC and so on.Customer special specification
also can be satisfied.
Technicial parameters
Hard-drawn Copper Catenary Wire DIN 48201 | ||||||||||||
Type | Nominal Area | Calculated Area | No.of Wire | Single wire Dia. | Linear Mass | Breaking Load | ||||||
(mm2) | (mm2) | (n) | (mm) | (±8% kg/km) | (≥kN) | |||||||
TJ | 10 | 10.2 | 7 | 1.35 | 90 | 4.02 | ||||||
16 | 15.89 | 7 | 1.70 | 143 | 6.37 | |||||||
25 | 24.25 | 7 | 2.10 | 218 | 9.72 | |||||||
35 | 34.36 | 7 | 2.50 | 310 | 13.77 | |||||||
50 | 49.48 | 7 | 3.00 | 446 | 19.84 | |||||||
50 | 48.35 | 19 | 1.80 | 437 | 19.38 | |||||||
70 | 65.81 | 19 | 2.10 | 596 | 26.38 | |||||||
... | ||||||||||||
Attention: We can provide more information than above data, if needed.The above are just some examples.
Application
Our other related products
Electrical wire/Cable
Bare cable (AAC, AAAC, ACSR, ...)
Rubber cable
ABC Cable (aerial bundle cable)
power cable
Control Power
If you are interested in our products, please click to contact us. Thank you very much!
Company Profile
Company Profile
People's Cable Group Ltd is a professional cable manufacturer in china, with more than 10 years' experience in cable field, located in Yongding Road, Gongyi City, Henan Province. Our company specialize in manufacturing high, medium and low voltage cable.
And our cable mainly include xlpe power cable, pvc insulated electric cable, fireproof cable, flame-retardant cable, control cable, rubber cable, insulated aerial cable coaxial cable, waterproof cable, aluminum stranded conductor, etc. we have exported to more than 40 countries, and receiving lots of high praise from our clients.
Certification
Packaging and delivery
Our customers
FAQ
Q: I didn't find the cable which I need in this page?
If you didn't find the species of cables you need, please contact us directly, we will reply you quickly.
Q: Are you a trading company or manufacturer?
We are professional manufacturer in Henan, China.
Q: What is the MOQ?
Mostly we sell from stock for normal items, you can buy any quantity unless it is customed-made.
Q: Can you offer me a free sample?
Yes, after price confirmation, you can require for samples to check our quality.
Q: How long to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days.
Q: How is your package?
Normally packed with coils and cartons, and wooden/steel wooden drums, other ways can be done according you.
Q: How is the payment?
T/T, L/C is accepted.
