All Aluminum Bare Conductor ACSR Conductor

All Aluminum Bare Conductor ACSR conductor

APPLICATION:
Used as bare overhead transmission conductor and as primary and secondary distribution conductor and messenger support.
ACSR offers optimal strength for line design. Variable steel core stranding enables desired strength to be achieved without sacrificing ampacity.

FEATURES:
ACSR conductors are recognized for their record of economy, dependability and favorable strength/weight ratio. ACSR conductors combine the light weight and good conductivity of aluminum with the high tensile strength and ruggedness of steel.
In line design, this can provide higher tensions, less sag and longer span lengths than obtainable with most other types of overhead conductors.
The steel strands are added as mechanical reinforcement. The cross-sections above illustrate some common stranding

CONSTRUCTION:
ACSR is a composite concentric-lay-stranded conductor.
The steel strand or strands form the central core of the conductor, around which is stranded one or more layers of aluminum 1350-H19 wires.
The steel core may consist of a single strand or a concentric-stranded cable of 7, 19, 37 or more wires. The sizes and stranding listed on the following pages are those most frequently used for overhead lines.

STANDARDS:
ASTM B232, BS 215 Part 2 , DIN 48204, IEC 61089, JIS C3110-78, NF C34-120

 As one of top rank cables manufacturers in China, our Zhitian factory is mainly specialized in PVC Insulated Building Wire, PVC and XLPE Insulated Power Cable with Voltage up to 35kV, Rubber Cable and Welding Cables. And the Zhulin factory is mainly specialized in Aerial Bundled Cable(ABC Cable), Bare Overhead Power Transmission Line such as triplex overhead service conductors(AAC Conductor), All Aluminum Alloy Conductor(AAAC Conductor), Aluminum Conductor Steel Reinforced(ACSR Conductor), Aluminum Conductor Aluminum Clad Steel Reinforced (ACSR/AW), All Aluminum Alloy Steel Reinforced(AACSR), and Aluminum Conductor Aluminum Alloy Reinforced(ACAR).

ASTM/BS/CSA/IEC standard overhead acsr Parrot/Martin/Snowbird/Mallard conductor acsr conductor

high tensile strength ACSR DOG conductor with BS 215 part 2 with factory price

ACSR LYNX

For more information, please kindly contact us freely!
Welcome your inquiry of ACSR bare conductor, please kindly inform us the section area, material, application, quantity you needed, so that we could quote accordingly.
