JBW-H Computer Automatic Instrumented oscilloscope izod impact test machine
Contact: Alice Zhang Skype: hssdtest What's APP / TEL: +86-15098778967
1.Introduction :
This izod impact test machine applicable to ISO14556:2000 Steel-charpy V-notch pendnlum impact test-Instvumented test method ;GB/T19748-2005 Metal charpy v-notch pendulum impact test instrumentation test method; GB/T3808-2002 Pendulum impact testing machine test. By testing the impact value, data collection and analysis of the impact process, energy change curve drawing, material fracture at different stages clear physics meaning and explanation, to study, analyze the material fracture behavior of the process, to provide accurate data in detail.
2.Standard : izod impact test machine
1. GB/T19748-2005 Steel charpy v-notch pendulum impact test (instruments) method
2. ISO 14556 : 2000 (E) Bend steel - charpy v-notch impact test - instrumented test method
3. ASTM E23 Steel charpy v-notch pendulum impact test instrument method
4. GB/T3808-2002 pendulum impact tester
5. JJG145 Pendulum impact testing machine verification procedures
3.Technical Parameters: izod impact test machine
Model | JBW-150H | JBW-300H | JBW-450H | JBW-600H | JBW-750H |
Control Way | Computer Control | ||||
Max. Impact Energy | 150J | 300J | 450J | 600J | 750J |
Impact Speed | 5.24m/s | ||||
Pendulum pre-raising Angle | 150 | ||||
Angle Accuracy | ±0.1° | ||||
Specimen Bearer Span | 40mm | ||||
Round angle of the jaw | R1.0~1.5mm | ||||
Round angle of impact edge | R2.0~2.5mm(R8mm) | ||||
Impact blade Angle | 30° | ||||
Impact blade thickness | 16mm | ||||
Distance between the Pendulum center and impact point | 750mm | ||||
Standard Specimen Size | 10×10(7.5 or 5)×55mm | ||||
Load Sensor Accuracy | ≤±1 FS | ||||
Angle Sensor Accuracy | 0.1° | ||||
Pendulum configuration | 150J | 300J | 450J | 600J | 750J |
Power Supply | Three-phase four-wire system 50Hz /380 | ||||
VU-2Y DWC-40/60/100 DWC-196 CST-50
1.Shipping & delivery: It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
2. Machine' Packaging: Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
Q:Are your company a trading one or a factory? izod impact test machine
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to delivery? izod impact test machine
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services? izod impact test machine
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?izod impact test machine
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
♥ More information welcome to contact us now!
And welcome to our company! We display more new design in our showroom.
♥ Main web site: : http://www.
Tel: 86 531-58618759| Fax: 86 531 86113759
