manual charpy testing/impact testing machine
Application:
The series impact testing machine is used to test the impact resistance performance of the metal materials under dynamic load.
The series impact testing machine manual controlled ,simple operate ,manual control is realized for pendulum rising,pendulum hanging,impacting and pendulum placing.the testing machine is suitable to be used in Metallurgy, machinery factory and other departments.JB-300 is designed for larger impact toughness ferrous metal .JB-50 apply to smaller toughness of ferrous metal
Main specification:
Model |
JB-300 |
JB-50 |
Impact energy |
150/300J |
25/50J |
Impact speed |
5.0m/s |
4.0 m/s |
Pre-rising angle of the pendulum |
135° |
|
Specimen bearer span |
40mm+0.2mm |
|
Round angle of the jaw |
R1.0-1.5mm |
|
Round angle of impact cutting edge |
R2-2.5mm |
|
angle accuracy |
± 0.1 ° |
|
Specimen size |
10mm×10mm×55mm |
|
The length of pendulum rod |
800mm |
478mm |
Dimensions |
1000×630×1520mm |
900×450×340mm |
the test machine weight |
320kg |
70kg |
Features:
1,The principle machine of the testing machine has single supporting column structure, cantilever type pendulum hanging mode; the pendulum body is U-shaped;
2,The impact cutter is installed and fixed by screws and is convenient and easy to be replaced;
3,The specimen is supported via simply by supported beam;
4,The testing machine is in conformity with the internationalGB/T3803- 2002 Testing of Pendulum Impact Testing Machine, and the impact test for metal materials is
carried out according to international GB/T229-2007 Metal Charpy Notch Impact Test Method.
