Mini Hydroelectric Power Micro Water Hydro Axial Flow Kaplan Propeller Turbine Thoma Turbine Electric Excitation Synchronous Permanent Magnet Brushless Generator Alternator Pico Turbine Generator for Homes
US$ 300 - 1600
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Enrich
Place of Origin:
China
Model Number:
ZD760-LM
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days
Related Products
-
Mini Micro Small Hydro Water Shaft-Extension Tubular S-Type Through Flow Hydroelectric Water Powered Propeller Turbine Electric Brushless Permanent Magnet Generator Alternator Sets for Home UseUS$ 300 - 1600MOQ: 1 Set -
0.6-3KW Mini Small Dual Wheel Impact Type Hydro Pelton Scoop Impulse Hydraulic Water Turbine Permanent Magnet Electric Brushless Generator Alternator Hidraulicas Turbina Pelton for Home Factory UseUS$ 300 - 500MOQ: 1 Set
-
High Voltage HV Outdoor Switchyard Switching Point Switching Station Substation Hydroelectric Power Station Hydro Electric Power Plant HPP HEPP SHPP SHEPP Solar Power PlantUS$ 10000 - 100000MOQ: 1 Set
-
Hydropower Hydroelectric Power Plant Automation Control System Protection and Monitoring System Relay Protection Cabinet Cubicle HPP HEPP SHPP SHEPPUS$ 10000 - 100000MOQ: 1 Set
-
Solar Hydropower Variable Programmable Switching Switch Mode AC DC Power Supply Source Supplies System Online Modular UPS Uninterrupted Uninterruptible Power Supply for Computer Data Center TelecomUS$ 1000 - 4600MOQ: 1 Set
Brand Name
Enrich
Place of Origin
China
Model Number
ZD760-LM
Type
Generator
Output Voltage (V)
220
Electricity Generator Type
Hydro Power
Axial turbine generator
Pico turbine generator for home use
Main components
No. |
Name |
Function |
1 |
Water turbine |
|
2 |
Generator |
|
3 |
Voltage controller |
Stable voltage |
4 |
Air switch |
Circuit protection |
Main technical parameters
Model |
Power KW |
Water head m |
Flow m3/s |
Pipe diameter mm |
Size cm |
Weight Kg |
Note |
ZD760-LM-12 |
0.6 |
1.2-2 |
0.018-0.05 |
13 |
25x25x80 |
30 |
Permanent magnet |
ZD760-LM-15 |
1 |
1.5-2.5 |
0.02-0.07 |
15 |
28x28x82 |
36 |
|
ZD760-LM-15 |
1.5 |
1.5-3 |
0.03-0.08 |
15 |
28x28x85 |
40 |
|
ZD760-LM-(18-20) |
2 |
1-3.5 |
0.08-0.1 |
18 |
33x33x98 |
60 |
|
ZD760-LM-(18-20) |
3 |
1.5-3.5 |
0.08-0.15 |
18 |
33x33x118 |
65 |
|
ZD760-LM-20 |
5 |
2.5-5.5 |
0.1-0.15 |
20 |
34x34x145 |
180 |
Excitation |
