0.6-3KW Mini Small Dual Wheel Impact Type Hydro Pelton Scoop Impulse Hydraulic Water Turbine Permanent Magnet Electric Brushless Generator Alternator Hidraulicas Turbina Pelton for Home Factory Use
US$ 300 - 500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Enrich
Place of Origin:
China
Model Number:
CJ22-W
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days
Related Products
-
High Voltage HV Outdoor Switchyard Switching Point Switching Station Substation Hydroelectric Power Station Hydro Electric Power Plant HPP HEPP SHPP SHEPP Solar Power PlantUS$ 10000 - 100000MOQ: 1 Set -
Hydropower Hydroelectric Power Plant Automation Control System Protection and Monitoring System Relay Protection Cabinet Cubicle HPP HEPP SHPP SHEPPUS$ 10000 - 100000MOQ: 1 Set
-
Solar Hydropower Variable Programmable Switching Switch Mode AC DC Power Supply Source Supplies System Online Modular UPS Uninterrupted Uninterruptible Power Supply for Computer Data Center TelecomUS$ 1000 - 4600MOQ: 1 Set
-
Temperature Rotary Speed Measuring Measurement and Oil Air Brake Control Cubicle Cabinet for Protecting Normal Start Acceleration Stop Running of Hydro Water Turbine GeneratorUS$ 1000 - 3000MOQ: 1 Set
-
Oil Immersed Epoxy Cast Resin Dry Type AC Electric Main Auxiliary Power Transformer Distribution Transformer With Conservator Power Substation Excitation Transformer Grounding Transformer Box Combination Type TransformerUS$ 500 - 100000MOQ: 1 Set
Brand Name
Enrich
Place of Origin
China
Model Number
CJ22-W
Type
Generator
Output Voltage (V)
220
Electricity Generator Type
Hydro Power
0.6-3KW Pelton turbine generator(also can connect with mini
diesel motor)
Pico turbine generator for home use
Main components
No. | Name | Function |
1 | Water turbine | |
2 | Generator | |
3 | Pipe | Diversion |
4 | Voltage controller | Stable voltage |
5 | Frame | Fix the unit |
6 | Air switch | Circuit protection |
Main technical parameters
Model | Power KW | Water head m | Flow m3/s | Pipe diameter mm | Size cm | Weight Kg | Note |
CJ22-W-13/1x2 | 0.6 | 9-18 | 0.008-0.01 | 75 | 35x30x30 | 40 | Permanent magnet |
CJ22-W-15/1x2.8 | 1 | 10-25 | 0.008-0.01 | 75 | 38x32x32 | 50 | |
CJ22-W-15/1x2.8 | 1.5 | 12-28 | 0.008-0.015 | 75 | 40x32x32 | 55 | |
CJ22-W-15/1x2.8 | 2 | 15-30 | 0.01-0.02 | 75 | 42x35x35 | 60 | |
CJ22-W-15/1x2.8 | 3 | 18-40 | 0.012-0.025 | 75 | 45x35x35 | 68 |
