Mini Micro Small Hydro Water Shaft-Extension Tubular S-Type Through Flow Hydroelectric Water Powered Propeller Turbine Electric Brushless Permanent Magnet Generator Alternator Sets for Home Use
US$ 300 - 1600
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Enrich
Place of Origin:
China
Model Number:
GL760-LM
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days
Related Products
-
0.6-3KW Mini Small Dual Wheel Impact Type Hydro Pelton Scoop Impulse Hydraulic Water Turbine Permanent Magnet Electric Brushless Generator Alternator Hidraulicas Turbina Pelton for Home Factory UseUS$ 300 - 500MOQ: 1 Set -
High Voltage HV Outdoor Switchyard Switching Point Switching Station Substation Hydroelectric Power Station Hydro Electric Power Plant HPP HEPP SHPP SHEPP Solar Power PlantUS$ 10000 - 100000MOQ: 1 Set
-
Hydropower Hydroelectric Power Plant Automation Control System Protection and Monitoring System Relay Protection Cabinet Cubicle HPP HEPP SHPP SHEPPUS$ 10000 - 100000MOQ: 1 Set
-
Solar Hydropower Variable Programmable Switching Switch Mode AC DC Power Supply Source Supplies System Online Modular UPS Uninterrupted Uninterruptible Power Supply for Computer Data Center TelecomUS$ 1000 - 4600MOQ: 1 Set
-
Temperature Rotary Speed Measuring Measurement and Oil Air Brake Control Cubicle Cabinet for Protecting Normal Start Acceleration Stop Running of Hydro Water Turbine GeneratorUS$ 1000 - 3000MOQ: 1 Set
Brand Name
Enrich
Place of Origin
China
Model Number
GL760-LM
Type
Generator
Output Voltage (V)
220
Electricity Generator Type
Hydro Power
Tubular turbine generator
Pico turbine generator for home use
Main components
No. | Name | Function |
1 | Water turbine | |
2 | Generator | |
3 | Voltage controller | Stable voltage |
4 | Air switch | Circuit protection |
5 | Pipe | Diversion |
Main technical parameters
Model | Power KW | Water head m | Flow m3/s | Pipe diameter mm | Size cm | Note |
GL760-LM-12 | 0.6 | 5-10 | 0.025-0.038 | 160 | 28x28x120 | Permanent magnet |
GL760-LM-15 | 1 | 5-10 | 0.03-0.04 | 160 | 28x28x120 | |
GL760-LM-15 | 1.5 | 5-10 | 0.04-0.045 | 160 | 28x28x120 | |
GL760-LM-(18-20) | 2 | 5-10 | 0.09-0.11 | 180 | 28x28x120 | |
GL760-LM-(18-20) | 3 | 5-10 | 0.09-0.14 | 180 | 28x28x120 | |
GL760-LM-20 | 5 | 5-10 | 0.0116-0.156 | 250 | 34x34x145 | Excitation |
