The function of fine fiber sieve
The fine fiber sieve is a kind of machine which uses the gravity and low centrifugal force of the slurry itself to separate the slurry through the sieve, which is mainly used to remove the fine fiber in the coarse starch slurry. It is the cassava starch processing process, the finer screening machine.
The composition and structure of fine fiber sieve
Its composition mainly includes the drum, the transmission system, the feeding system, the backwash system, the spray system and so on. All parts that touch the raw material are made of stainless steel.
The working principle of fine fiber sieve
When the fine slag sieve is in operation, the starch slurry enters the drum through the feeding port. The drum is composed of the bottom mesh frame and the surface mesh. The driving system drives the roller to rotate at a constant speed, which drives the starch slurry to move on the roller.
Then spray rinse starch granules, small starch granules can pass through the surface screen, and discharge from the aggregate mouth, while fine fiber and other impurities remain on the screen, and discharge from the slag mouth.
The technical parameters of fine fiber sieve
Model |
Drum diameter (mm) |
Main shaft speed (r/min) |
Power (kw) |
Dimension (mm) |
Weight (t) |
Capacity (t/h) |
Roller length (mm) |
Φ1005 |
21 |
3.0 |
4300×1380×1610 |
2.5 |
2-4 |
3300 |
|
DYXS-2x95 |
Φ950 |
21 |
2.2×2 |
6000×1550×2300 |
3.8 |
3-6 |
5000 |
The features of fine fiber sieve
1. All parts that touch the materials are made of stainless steel to ensure that the materials are free from external contamination
2. The whole machine has large processing capacity and low energy consumption
3. Stable operation, easy to install and maintain
4. The automatic front and back washing system improves the permeability of the screen and ensures the stable operation of the equipment.
5. Starch sieving effect is good
