we,TOPPOWER can produce: TOPPOWER quality : ISO9001:2015, IATF16949:2016 |
| Brand: | TOPPOWER |
| size: sip | 11.48*6*7.46mm |
| PACKAGING: | sip/dip |
| power: | 1w |
| Price: | 2.00$/Pieces |
| Min.Order: | 100 Pieces |
| Supply Amount: |
50000 Pieces |
| Delivery: | Shipment within 7 days since the date of payment |
| Address: | China |
1W Isolated unRegulated Single Output DC/DC Converters
The TKE series are miniature, isolated 1W DC/DC converters in a SIP and DIP package. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency.
TOPPOWER can produce:
0.1W-40W DC-DC converters,3W-30W AC-DC converters,(SIP/DIP/SMD)
15W-1200W Enclosed /Open frame/DIN RAIL type AC-DC Switching Power supply,
TOPPOWER quality : ISO9001:2015, IATF16949:2016
isolated voltage: 1.5KVDC ,2KVDC,3KVDC,4KVDC,6KVDC,10KVDC,3KVAC,4KVAC.
Part NumberNominal Input VoltageOutput Voltage
VV
TKE0303D3.33.3
TKE0305D3.35
TKE0309D3.39
TKE0303S3.33.3
TKE0305S3.35
TKE0309S3.39
TKE0503D53.3
TKE0505D55
TKE0509D59
TKE0512D512
TKE0515D515
TKE0503S53.3
TKE0505S55
TKE0509S59
TKE0512S512
TKE0515S515
TKE1205D125
TKE1209D129
TKE1212D1212
TKE1215D1215
TKE1205S125
TKE1209S129
TKE1212S1212
TKE1215S1215
Add suffix “P” for continuous short circuit protection, for example TKE0505SP.
Add suffix “/H” for3KVDC isolated for SIP version, for example TKE0505S/H.
