ZIPO stainless steel unsealed vertical self-priming pump automatic self-priming pump sewage pump ZWFB type
Contact: Email: zipopvf@163.com Wechat: zipo2019; QQ: 2191417589; Mobile: 18081659672
Please inform us of the accurate flow, head, pipe loss, medium specific gravity, motor power and other parameters, before consulting or purchasing the product. Thanks!
ZWFB type unsealed self-control self-priming pump is a new type of product, which has many functions such as temperature and pressure resistance, "one-time water filling" and "life-long self-priming". Main material would be stainless steel, reinforced polypropylene, cast steel, cast iron and others. It is widely used in electronics, power, chemical industry, metallurgy, medicine, food, electroplating, environmental protection, fire protection, municipal administration, water purification, textile printing and dyeing, mining and mineral processing, civil construction and other industries.
Unique advantages:
1. The company adopts the "multi-faceted centrifugal sealing device for pumps, which eliminates "running, emitting, dripping and leakage" of the packing seal and mechanical seal of the traditional water pump, It is a substitute for the original long shaft submerged pump, submersible pump or submersible pump.
2. During operation, the sealing device has no friction and damage, and its service life is more than 10 times longer than that of similar products.
3. Transplantation of vacuum pump principle, self-priming performance is stable and reliable, especially the use of "electric air control valve", truly achieve "once water filling, life-long self-priming".
4. It has the advantages of small vibration, low noise, flexible movement, easy disassembly, easy installation and no need of anchor fixation.
5. It has superior automatic control function and can be used with automation system.
Application characteristics of different shapes:
Rectangular type and conical type provide you with different installation options; explosion-proof type is suitable for inflammable and explosive environment; outdoor type can effectively prevent rain, fog, moisture and humidity when working in the open air with the help of safe three-dimensional housing cover; trolley mobile type can move the water pump to the position you need.
Flow range: 0.75m3/h ~ 6850m3 / h, lift head range: 6m ~ 130m
Suction diameter: DN 16mm ~ DN800mm
Matching power: 0.75KW ~ 315KW speed: 1450r / min or 2900r / min,
Allowable suction depth: 3M ~ 8M
Material: cast iron HT, cast steel WCB, stainless steel 304, 34L, 316L
Models: 0ZWFB, 65ZWFB, 80ZWFB, 100ZWFB, 125ZWFB, 150ZWFB, 200ZWFB, 250ZWFB, 300ZWFB, 350ZWFB, 400ZWFB, 450ZWFB, 600ZWFB, 800ZWFB
Manufacturer: ZIPO VALVE & PUMP CO., LTD
