Desilter
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
BZ
Place of Origin:
China
Model Number:
BZCN
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
BZ
Place of Origin
China
Model Number
BZCN
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
1 year
Certification
ISO
Condition
New
Desilter is the third phase solids control equipment to treat drilling fluid, usually working between desander and centrifuge. The most common cone diameter is 4”, mainly to separate solids in 15-45μm. Quantity of hydrocyclones can be adjusted according to treating capacity demand. An underflow shale shaker is optional.
BZCN Desilter Specification
| Model | BZCN100-6N | BZCN100-8N | BZCN100-12N | BZCN100-16N |
| Capacity | 90m³/h | 120m³/h | 240m³/h | 360m³/h |
| Desilter Size | 4inch | |||
| Desilter Qty(pcs) | 6 | 8 | 12 | 16 |
| Working Pressure | 0.25-0.4MPa | |||
| Particle Size | 15um-45um | |||
| Shaker | BZS60 | BZS752 | ||
| EX Standard | ExdIIBt4/IECEX/A-TEX | |||
| Dimension | 1510X1360X1810mm | 1510X1360X1810mm | 1835X1430X2085mm | 1835X1430X2085mm |
Features
· 100% Polyurethane(PU) Material for desander cones with longer using life
· High separation efficiency, 15-45um drilling cuttings can be separated
. Quantity fo hydrocyclones can be adjusted by different treatment capacity request
· Compact design with small footprint
· Different size of shale shaker are optional
. Spraying nozzle design of cone outlet, no block problem
· Famous brand vibration motors : IEC Ex, ATEX and UL certified
· Electrical components: SIEMENS, Schneider
