Introduction
R-type Raymond Mill after many years of practice and continuous improvement, its structure has been improving.Which is widely used in metallurgy, building materials, chemicals, mining minerals in areas,such as grinding materials processing, suitable for processing the following seven Mohs hardness, moisture below 6% for various non-flammable minerals, such as gypsum,talc, calcite, limestone, marble, feldspar, barite, dolomite, granite, kaolin, bentonite, stone, iron oxide red, iron ore, 280 kinds of materials,the fineness of the finished product 0.198-0.044mm (80 mesh-325 mesh) between the machine and the fan through the analysis of the joint action, can meet different requirements of users.
Advantages
1. 100% China factory price
2. Direct sales, no middleman, fast delivery.
3. Easy to transport and install
Smaller space, easier to transport, install, operate and maintain.
4. Fineness can be adjusted freely
Product fineness can be adjusted freely between 80-325 mesh, and the applicability is more flexible and extensive.
5. Low cost and high yield
|
|
Main Technical Parameter
Model |
Number of roll grinding |
Grinding roll size (mm) |
Grinding ring inner diameter and height (mm) |
Max feed size (mm) |
Finished size (mm) |
Capacity (t/h) |
Host power (kW) |
Weight (t) |
Dimension (mm) |
3R1510 |
3 |
150X100 |
570X100 |
15 |
0.198-0.044 |
0.3-1.2 |
7.5 |
2.0 |
3200X2100X3800 |
3R2115 |
3 |
210X150 |
630X150 |
15 |
0.198-0.044 |
0.4-1.6 |
15 |
3.6 |
4100X3300X4500 |
3R2615 |
3 |
260X150 |
780X150 |
20 |
0.198-0.044 |
0.8-2.5 |
18.5 |
4.2 |
4300X3500X5100 |
3R2715 |
3 |
270X150 |
830X150 |
20 |
0.198-0.044 |
0.9-3 |
22 |
4.8 |
4500X4100X5200 |
3R3015 |
3 |
300X150 |
875X150 |
20 |
0.198-0.044 |
1.2-4 |
30 |
5.3 |
4800X4100X5200 |
4R3016 |
4 |
300X160 |
890X160 |
20 |
0.198-0.044 |
1.5-4 |
30 |
8.5 |
6500X4100X5200 |
4R3216 |
4 |
320X160 |
970X160 |
25 |
0.198-0.044 |
1.8-6 |
37 |
15 |
7900X5800X9100 |
5R4119 |
5 |
410X190 |
1280X190 |
30 |
0.198-0.044 |
3-10 |
75 |
24 |
9200X8000X9700 |
Remark：3R1510,3R2115,3R2615, 3R2715 and 3R3015 is the weight of mill. 4R3016,4R3216 and 5R4119 is the weight of whole set equipment.
Structure of raymond mill
The structure of the Raymond mill is mainly composed of a host machine, an analyzer, a fan, a finished cyclone separator, a micro powder cyclone separator and an air pipe. Among them, the host is composed of a machine frame, inlet volute, blade and grinding roller and grinding ring and shell composition.
