Product Introduction
As the most widely-used equipment, vibrating mill is a new highly-efficient powder making machine. It has single shell, double shell and three-shell types. It uses high frequency vibration of shell and the inertia force of steel ball or steel rod in the shell to impact materials. The acceleration can reach to 10g-15g when the medium impacts materials. Therefore, it has many advantages: compact structure, small size, lightness, low energy consumption, high output, concentrated granularity, simplified process, simple operation, convenient maintenance and easy renewal for liner medium. It's mostly applied in metallurgy, construction, mine, refractory, chemical, glass, ceramics and graphite industries.
Working Principle
The motor drives the shaft of the vibration exciter to rotate through the flexible coupling and the universal coupling. There is an eccentric block on the shaft. The rotation of the shaft urges double shells to do similar round vibration. The shell is filled with grinding medium (steel ball or steel rod) and materials. Materials can enter from the inlet of the upper shell and then flow into the lower shell. At last, they will be discharged, that is, single in and out; materials can enter both shells simultaneously and then are discharged at the same time, that is, double in and out or double in and quadruple out. During the round vibration, the medium and materials revolve inside the shell and impact with each other. This regular revolving, impact and the rotation of the medium make materials crushed in a short time which can achieve ideal crushing effects.
Performance Characteristics
1.Small floor area, easy installation and isolation.
2.Low energy consumption per unit of output.
3.Concentrated grinding granularity.
4.Lightness, high output and weight ratio.
5.Low noise.
6.Simple process, convenient maintenance.
7.Easy renewal of liner and the medium.
8.Being unaffected by the acceleration with the best index of 0.8g, small grinding medium, big change per unit of grinding surface.
Model
Model |
Content |
|
Number of Shell（No note for single shell, 2 is double-shell, 3 is three-shell） |
MZ |
Vibrating Mill |
|
Total Volume of Shell, L |
Technical Parameters
Single Shell Vibrating Mill | |||||
Model |
MZ-100 |
MZ-200 |
MZ-400 |
MZ-800 |
MZ-1600 |
Shell Volume L |
100 |
200 |
400 |
800 |
1600 |
Outer Diameter mm |
560 |
710 |
900 |
1120 |
1400 |
|
Oscillation Frequency Hz |
24 |
24.3 |
24.5 |
16.3 |
16.2 |
Amplitudemm |
≦3 |
≦7 |
|||
Grinding Medium Volume L |
65~85 |
130~170 |
260~340 |
520~680 |
1040~1360 |
Feed Granularity mm |
≦5 |
||||
Discharge Granularity um |
≦74 |
||||
Capacity kg/h |
100 |
200 |
400 |
800 |
1600 |
Power kw |
5.5 |
11 |
22 |
45 |
90 |
Vibration Parts Weight kg |
≦380 |
≦610 |
≦1220 |
≦2450 |
≦4900 |
|
Note 1: The amplitude refers to the peak value of simple harmonic oscillation. Note 2: Capacity is the one when grinding red clay. | |||||
Double-shell Vibrating Mill | |||||
|
Model
|
2MZ-100 |
2MZ-200 |
2MZ-400 |
2MZ-800 |
2MZ-1600 |
|
Shell Volume L |
100 |
200 |
400 |
800 |
1600 |
|
Outer Diameter mm |
224 |
180 |
255 |
450 |
560 |
|
Oscillation Frequency Hz |
24 |
24.3 |
24.5 |
16.3 |
16.2 |
|
Amplitude mm |
≦3 |
≦7 |
|||
Grinding Medium Volume L |
65~85 |
130~170 |
260~340 |
520~680 |
1040~1360 |
|
Feed Granularity mm |
≦5 |
||||
|
Discharge Granularity um |
≦74 |
||||
|
Capacity kg/h |
90 |
180 |
350 |
700 |
1400 |
Power kw |
7.5 |
15 |
30 |
35 |
110 |
Vibration Parts Weight kg |
≦540 |
≦960 |
≦1910 |
≦3820 |
≦7650 |
|
Note 1: The amplitude refers to the peak value of simple harmonic oscillation. Note 2: Capacity is the one when grinding molasse. | |||||
