General Description
AKE392B three-axis accelerometer sensor series products is RION company imported the Switzerland patented technology to produce for using widely, suitable for vibration testing, impact testing and more fields. The product uses a digital interface output, RS232/485/TTL optional, can be set to a different address code, long distance series with multiple sensors to facilitate multi-point measurement and data analysis.AKE392B is a monocrystalline silicon capacitive sensor, composed by a silicon chip of micro-mechanical treatment, low power ASIC for the signal adjustment, a microprocessor for storing compensation value and a temperature sensor. The product with low power consumption, after calibration, firm structure, stable output . New electronic configuration reset to provide a solid-state power, to provide comprehensive protection for over current. Scale factor in the full range of long-term stability and the deviation is typically less than 0.1%.This series products with firm structure,low power consumption, excellent deviation stability .etc characteristics to guarantee the reliability of outstanding output .
Key Features
●Three axis measurement optional (X、Y、Z) ●Output signal：RS232/RS485/TTL
●Voltage supply：9-36V ●Shock resistance：2000G
●Measuring range optional：±01G；±02G；±04G；±08G；±16G；±32G；±40G
●Excellent deviation stability ● Good environment performance shock，vibration and temperature）
●Size：L50×W50×H38mm ●Weight：100g
●Working temperature：-40°C to +85°C ●Storage temperature：-55°C to +100°C
Application
● Crash records, fatigue monitoring and forecasting
● Traffic system monitoring, the roadbed analysis and high-speed railway fault detection
● Military and civilian flight simulator ● The shipboard satellite tracking system
● Low frequency vibration and automatic monitoring
